Alesis iO Dock II Service Manual

LXANALE11 BOM
LEVEL
P/N DESCRIPTION QTY REF
0
LXANALE11 IODOCKII AC110V/50V(USA) 0
1 AL7-10-1215 Switching ADAPTOR(UL/JIS) DC12V/2A 1
1
AL9-23-0023 RUBBER 4
15
1 BART-K00701 Rotate Knob 4
12
1
CA120901501 iPad Cable 150mm mini USB/Housing Black 1
18
1 LAC62ALE373 Bar Code Label(CODE 39) 0.5
1
LAC62ALE381 Bar Code Label 0.5
1 MT0705517 Copper 1
1
MT13044176 Thumb SCREW 1
10
1 NM1301821 Electic Corduction Copper Plate 1
1
PLXANALE11 Pack Assembly 1
2 AL7-51-0154-R Safety Manual 1
2
AL7-51-0335-F Manual Quickstart 1
2 AL7-91-1002 Gel Silica 1
2
BC1015011050 Bubble Pad 1
2 CGLXAN310ALE01 GIFT Box 1
2
CTLXAN513ALE01 Carton 0.5
2 LAC22ALE372 Serial Number Label 1
16
2
LAC53AKA309 Safety Label 1
17
2 LAC67YAH261 Label φ8mm Green 1
2
LAP67YAH255 Sticker φ10mm red 3
2 PE150350BO Poly Bag 150*350mm 1
2
PLLXAN01 Polyfoam(LEFT) 1
2 PLLXAN02 Polyfoam(RIGHT) 1
2
SD35035000 Soft Sheet 1
1 PT1304315 Power Cable Retainer 1
11
1
PT1304342 iPAD2 Lock 1
6
1 PT1304491 IPAD Holder 1
4
1
PT130449502 Top Panel Frame(Printing & Painting) 1
1
2 PT1304495 Panel Cover 1
1
PT1304496 IPAD2 Holder 1
5
1 PT133002301 Top Panel (Paint Black) 1
3
2
PT1330023 Top Panel 1
1 PT133034301 Bottom Panel(Paint) 1
14
2
PT1330343 Bottom Panel 1
1 PT1510643 ALPHA Knob 1
8
1
SC0306RBNI Screw M3X6 PRN Tapping 11
13
1 SC0308PBBI Screw M3X8 PBB Tapping 23
7
1
TP0214190T TAPE 3
2
1 TWBRI10-09B01 Bridge 10Pin mini USB To 30Pin Assembly 1
2
JKMFI677-0637-3 Lightning Connector MFI C10A-3 1
1 TWBRI10-30B01 Bridge 10Pin mini USB To Lightning Assembly 1
2 JK512S0017-1 IPAD Connector 1
1
TWPC13A02201 Main PCB Assembly 1 9
2 PC13A022 Main PCB 2 Layer 1fr-4 1.6T 160*258mm 1
2 TWPC13A022A01 Main PCB Assembly 1
3 AA822748X Diode BAV99 3 D1,2,23
3 AL2-50-4149 Diode Single 1N4148 100V 200mA SOT-23 10 D3,9~12,16,17,19~21
