Alesis iO Hub Service Manual

Level 1 BOM
#Number Part Name Description
10520198 Switch Cap Aluminum Anodized,V1.0
10520204 Battery Chip One side 9V battery,another side 2.0,UL1007,28,black and black,L=70mm
10550002 Metal Plate DN-SE002,SPCC,T=3mm,black zinc plate,V1.0
20060025 Battery Cap DN-PC6013,ABS(UL94HB),black, texture,ROHS,V1.0
20070023 Left Side Panel DN-PC7019,Left Panel,ABS(UL94HB),black, chrome plate,ROHS,V1.0
20070024 Right Side Panel DN-PC7020,Right Panel,ABS(UL94HB),black, chrome plate,ROHS,V1.0
20080030 Back Panel DN-PC8028,ABS(UL94HB),black plate,ROHS,V1.0
20110099 Lens DN-PL1080,lens-2,acrylic, texture,V1.0
20210136 Rotary Cap DN-PN2098,ABS(UL94HB),black, chrome plate,ROHS,V1.0
20300107 Feet black rubber,Φ8-5mm,one sided glue,V1.0
54110017 Lens DN-PL1079,lens-1,PC,T=1mm,with silkscreen V1.0
54280004 Front Panel DN-EC012,ABS(UL94HB),with silkscreen,V1.0
70010075 Full Threaded Screw Φ3*8mm,hexagon,D5mm,black zinc
70010810 Full Threaded Screw M3*6mm,hexagon,D5.5,black zinc
CR010585 RoHS Semi Assembled LXAH MAIN ASSY
CR010586 RoHS Semi Assembled LXAH MAIN SMT ASSY
16160008 USB Cable
A
N-U0008,UL2725,28#,1000MM,one end USB-A, another end MINI USB-5
P
22010710 Safety Manual ALESIS,safety manual,7-51-0154-R
22010830 User Guide LXAH,user guide,V1.0
23031169 Master Carton A=A,V1.0
23090491 Giftbox 300G+CE,V1.0
23150027 Paper Tray LXAH,100%,T=1.5mm,ROHS,V1.0
51020023 Battery 9V battery
90021185 Specific Sticker 55*13mm,V1.0
90041257 Barcode Sticker 90*42mm,V1.0
90080001 Destination Sticker GA0/GA1/GA2
90200056 Marking Sticker BLACK&361C,Φ30mm,V1.0
90220078 Unique Sticker ALESIS,30*30mm,PANTONE 361C,V1.0
