Alesis iO Hub Service Manual

Engineering BOM
Item Part Name Description Qty
1 PCB FR4 four layered board,71MM*120MM 绿色,1盎司 1
2 Rotary VR RD902F-20E1-15F-B10K-00D28（艾华） 2
3 Rotary VR RD901F-20-15F-A50K-00D（艾华） 2
4 SMD Resistor 1/10W,0Ω,±5%,0603 8
5 SMD Resistor 1/10W,1Ω,±1%,0603,编带式 3
6 SMD Resistor 1/10W,5.1Ω,±5%,0603 1
7 SMD Resistor 1/10W,22.1Ω,±1%,0603 2
8 SMD Resistor 1/10W,47Ω,±5%,0603 7
9 SMD Resistor 1/10W,470Ω,±5%,0603 1
10 SMD Resistor 1/10W,510Ω,±1%,0603 2
11 SMD Resistor 1/10W,1KΩ,±1%,0603,编带式 15
12 SMD Resistor 1/10W,1.13KΩ,±1%,0603 2
13 SMD Resistor 1/8W,1.21KΩ,±1%,0805 4
14 SMD Resistor 1/10W,1.5KΩ,±1%,0603 8
15 SMD Resistor 1/10W,3.65KΩ,±1%,0603 4
16 SMD Resistor 1/10W,3.9KΩ,±5%,0603 3
17 SMD Resistor 1/10W,7.32KΩ,±1%,0603 4
18 SMD Resistor 1/10W,10KΩ,±1%,0603 20
19 SMD Resistor 1/10W,20KΩ,±1%,0603 1
20 SMD Resistor 1/10W,21KΩ,±1%,0603 2
21 SMD Resistor 1/10W,41.2K,±5%,0603 2
22 SMD Resistor 1/10W,49.9KΩ,±1%,0603,编带式 1
23 SMD Resistor 1/10W,62KΩ,±5%,0603 1
24 SMD Resistor 1/10W,100KΩ,±1%,0603 6
25 SMD Resistor 1/10W,470KΩ,±5%,0603 1
26 SMD Resistor 1/10W,820KΩ,±5%,0603 3
27 SMD Resistor 1/10W,1MΩ,±1%,0603 1
28 SMD Resistor 1/10W,1MΩ,±1%,0603 1
29 SMD Resistor 1/8W,33.2Ω,±5%,0805 2
30 SMD Resistor 1/8W,1KΩ,±1%,0805 4
31 SMD Resistor 1/8W,15K
Ω,±1%,0805 8
32 SMD Resistor 1/8W,47KΩ,±1%,0805 4
33 SMD Resistor 1/8W,100KΩ,±1%,0805 4
34 SMD Ceramic Capacitor 10PF,VDC50,±5%,NPO,0603,编带式 9
35 SMD Ceramic Capacitor 18PF,VDC50,±5%,NPO,0603,编带式 3
36 SMD Ceramic Capacitor 33PF,VDC50,±5%,NPO,0603,编带式 9
37 SMD Ceramic Capacitor 47PF,VDC50,±5%,NPO,0603,编带式 2
38 SMD Ceramic Capacitor 101,VDC50,±5%,NPO,0603,编带式 18
39 SMD Ceramic Capacitor 121,VDC50,±10%,X7R,0603,编带式 2
40 SMD Ceramic Capacitor 151,VDC50,±10%,X7R,0603,编带式 2
41 SMD Ceramic Capacitor 221,VDC50,±5%,NPO,0603,编带式 2
42 SMD Ceramic Capacitor 391,VDC50,±10%,X7R,0603,编带式 4
43 SMD Ceramic Capacitor 222,VDC50,±10%,X7R,0603,编带式 1
44 SMD Ceramic Capacitor 103,VDC50,±10%,X7R,0603,编带式 1
45 SMD Ceramic Capacitor 104,VDC50,±10%,X7R,0603,编带式 14
46 SMD Ceramic Capacitor 1UF,VDC10,±10%,X7R,0603, 编带式 4
47 SMD Ceramic Capacitor 471,VDC50,±10%,X7R,0805,编带式 8
48 SMD Ceramic Capacitor 102,VDC50,±10%,X7R,0805,编带式 1
49 SMD Ceramic Capacitor 104,VDC50,±10%,X7R,0603,编带式 18
