XF7ALE BOM
2
AL0-15-0272 RESISTOR 2 R97,120
2
AL0-15-0331 RESISTOR 330 (SMD) 5% 22
R12,13,20,21,23,24,31,45,52,61,71,77,89
R98 101 106 112 113 121 128 130 134
2
AL0-15-0332 RESISTOR 4 R114,119,125,126
2
AL0-15-0472 RESISTOR 1 R2
2
AL0-15-0512 RES 5.1K (SMD) 1/10W 5% 0805 52
R1,3,5~7,10,11,14,17,19,22,26,28,30,34
R35 38 40 43 44 49 51 56 60 63 65 67 75
2
AL0-15-0822 RES 8.2K (SMD) 1/10W 5% 0805 2 R25,29
2
AL0-16-1202 RES 12.0K (SMD) 1/10W 1% 0805 4 R115~118
2
AL0-16-5111 RESISTOR 2 R55,74
2
AL0-16-5629 RESISTOR 56.2Ω0805 SMD 1% 12 R42,47,48,54,58,59,64,68~70,107,108
2
AL0-16-6341 RES 6.34K(SMD) 1/10W 1% 0805 1 R62
2
AL1-55-0209 CAP 20PF NPO 0805 10 C14,15,33,34,48,49,59,60,70,71
2
AL1-55-0561 CERAMIC 8 C9,23,28,44,47,56,57,73
2
AL1-55-0751 CAP 750PF NPO 0805 2 C87,88
2
AL1-56-0100 CERAMIC 3 C6,24,31
2
AL1-56-0101 CAP 100PF NPO 0805 2 C11,12
2
AL1-56-0102 CREAMIC 9 C41~43,58,64,68,74,84,92
2
AL1-56-0103 CERAMIC 9 C10,20,26,29,35,37,46,51,66
2
AL1-56-0105 CERAMIC 3 C36,38,53
2
AL1-56-0150 CAP 15PF NPO 0805 2 C21,22
2
AL1-56-0221 CAP 220PF X7R 0805 6 C45,65,80~83
2
AL1-56-0471 CERAMIC 2 C2,19
2
AL1-60-2222 ELECT 34
C3~5,8,13,16,18,25,27,30,32,39,40,50,52,54,55
C63 67 69 72 75 79 85 86 89 91 93 94 96
2
AL1-61-0221 CAP 220PF X7R 0603 50V 12 C188~199
2
AL1-62-0104 CAP 0.1UF X7R 10% 0603 91 C97~187
2
AL1-73-1103 CAP 4 C1,61,62,90
2
AL2-61-2317 IC 2 U1,19
2
AL2-61-7807 IC 1 U20
2
AL2-62-0005 IC 2 U3,16
2
AL2-70-0010 IC DICEII 1 U6
2
AL2-71-0074 IC 3 U4,9,14
2
AL2-75-1101 IC 5 U2,5,7,10,15
2
AL2-75-1201 IC 1 U17
2
AL2-79-3305 IC 1 U18
2
AL2-84-0041 IC TSB41AB2 1 U8
2
AL4-08-0601 1394 6-PIN PLUG 2 (J2,3)
2
AL4-15-0600 CONNECTOR 1 (J7)
2
AL7-20-0070 BEAP 0805 SMD 5 L6,7,12,13,15
2
AL7-20-0071 BEAD SMD 1806 10 L1~5,8~11,14
2
AL7-60-0003 CRYSTAL 24.576MHZ 1 Y2
2
AL9-40-0386 FIREWIRE MAIN PCB 1 -
2
AL9-61-0143 IC 1 U13
2
AL2-69-6160 IC 1
2
ICK4S641632E SDRAM IC 1 U12
2
TE10200702 CONNECTOR(7P SOCKET) 1 (J4)
2
TE612000202 CONNECTOR 2P 2.0 180° 1 (J5)
2
TE962001601 CONNCTOR(16P) 1 (J1)
2
TE962541401 CONNECTOR 1 (J6)
1
AL9-79-038701 EXPANSION PCB ASS'Y 1 33
2
AL0-15-0103 RESISTOR 1 R55
2
AL0-15-0331 RESISTOR 330 (SMD) 5% 12 R1~3,12~15,21~25
2
AL0-15-0512 RES 5.1K (SMD) 1/10W 5% 0805 40 R4~11,16~20,26,27,29~53
2
AL1-55-0209 CAP 20PF NPO 0805 8 C31~34,42,43,50,51
2
AL1-55-0561 CERAMIC 8 C7~9,14,15,22,23,44
2
AL1-56-0104 CERAMIC 20 C1~6,10~13,16~21,35,52,54,56
2
AL1-60-2222 ELECT 20 C24~30,36~41,45~49,53,55
2
AL2-61-7807 IC 1 U8
2
AL2-71-0074 IC 2 U6,7
2
AL2-75-1101 IC 4 U1~4
2
AL9-40-0387 EXPANSION PCB 1 -
2
TE962001601 CONNCTOR(16P) 1 (J2)
2
TE962541401 CONNECTOR 1 (J1)
1
AL9-79-0302-02 MAIN PCB ASS'Y 1 15
