Alesis MultiMix FireWire 16 - Page 49

XF7ALE BOM
2
AL1-56-0104 CERAMIC 4 M_C1,M_C2,M_C5,M_C15
2
AL2-27-0060 IC 1 M_IC2
2
AL7-01-0033 CRYSTAL 12MHZ 1 M_M1
2
AL9-61-0106 IC 1 M_IC1
2
AL2-70-8754 IC 1
2
EC22716TS ELECT ACP 220UF/16V(S) 1 M_C3
2
LDT2601G LED 1 M_LED1
2
MT1303214 FIXED PLATE 1 (M_IC2)
2
RS10118J05 RES 100Ω 5% 0805 SMD 3 M_R1,M_R16,M_R17
2
RS22118J05 RESISTOR 220Ω(SMD)5% 8 M_R6~M_R13
2
RS47018J05 RESISTOR 47Ω(SMD) 3 M_R4,M_R14,M_R15
2
RS47118J05 RESISTOR 470Ω(SMD) 2 M_R2,M_R3
2
TE162000601 TERMINAL 2 (M_TE1,M_TE3)
2
TRBC857B TRANSISTOR 2 M_Q1,M_Q2
1
AL9-79-0320 POWER PCB ASS'Y 1 44
2
AL1-56-0104 CERAMIC 1 C562
2
CS221J5005COG CAPACITOR 1 C561
2
MT1304439 HOLDER PLATE 1 -
2
RJ1081 1PIN RCA JACK 1 J30
2
RS10118J05 RES 100Ω 5% 0805 SMD 1 R780
2
TE612000202 CONNECTOR 2P 2.0 180° 1 (PTE7)
2
WR1317012B CONNECTOR 1 PTE7
1
AL9-79-0388 POWER PCB ASS'Y 1 42
2
AL0-16-1691 RESISTOR 16.9K SMD 1% 1 PR10
2
AL0-16-8871 RESISTOR 8K87Ω 0805(SMD)1% 1 PR8
2
AL1-56-0104 CERAMIC 12 PC20~31
2
AL4-15-0600 CONNECTOR 1 (PJ3)
2
DI1N5402T DIODE 2 PD5,6
2
DIN4002 DIODE DIN4002 6 PD1~4,7,8
2
DIN5819TP-MIC DIODE 2 PD11,12
2
DIZBZX79C47V ZENER DIODE 1 PD9
2
EC107100 ELECTRIC CAPACITOR 1 PC5
2
EC10735TLE E. CAPACITOR 2 PC13,18
2
EC10835 E.CAPACITOR 1 PC11
2
EC22835 ELEC CAPATOR 2200UF/35V 1 PC9
2
EC33725TLE E. CAPACITOR 2 PC14,19
2
EC476100 ELECTRIC CAPACITOR 2 PC3,4
2
EC47625T ELECTRIC CAPACITOR 2 PC10,12
2
EC47650T ELECTRIC CAPACITOR 2 PC6,7
2
IC7815 INTEGRATE CIRCUIT 1 PIC1
2
IC7915 INTEGRATE CIRCUIT 1 PIC2
2
ICLM2575 IC LM2575 2 PIC3,4
2
R10018 RESISTOR 1 PR1
2
R10318 RESISTOR 1 PR2
2
R20318 RESISTOR 1 PR4
2
R39418 RESISTOR 390K 1/4W 1 PR3
2
RS10218F05 RESISTOR 2 PR9,11
2
TE11032501 TERMINAL(3P) 1 PIC5
2
TE612000202 CONNECTOR 2P 2.0 180° 1 (PTE1)
2
TE612000301 TERMINAL(3P) 180° 1 (PTE4)
2
TE612000402 TERMINAL(4P) 1 (PTE3)
2
TE612000801 8P CONNECTOR 180° 1 (PTE2)
2
TRBD239C TRANSISTOR 1 PQ1
2
UHFS4W1010-331K CAPACITOR 2 PL2,3
1
AL9-79-0401 5V POWER PCB ASS'Y 1 45
2
AL1-56-0104 CERAMIC 2 PC16A,17A
2
CN0325001001 CONNECTOR 3P 100MM 1 PTE5
2
EC10725T CAPACITOR 100UF/25V 1 PC15A
2
IC7805 I.C. 7805 1 PIC5A
1
AL9-79-0391 MIXER PCB ASS'Y 1 24
