XF7ALE BOM
2
AL0-16-1472 RESISTOR 4 R185,227,229,230
2
AL0-16-6041 RESISTOR 2 R152,153
2
AL0-16-7321 RESISTOR 4 R187~190
2
AL1-56-0104 CERAMIC 118
C9,18,20,25,39,43,44,47,49,50,64,70,73
2
AL2-52-0011 DIOED 16 D51~66
2
AL2-71-0074 IC 1 IC17
2
AL2-71-4580 IC 46 IC1~13,18~22,24~28,31~35,37~45,48~56
2
AL2-72-0339 IC LM339 SOP-14 5 IC16,23,29,30,36
2
AL2-75-1101 IC 1 IC14
2
AL2-75-1201 IC 1 IC15
2
AL6-00-0008 ENCODER 1 VR21
2
AL9-40-039101 MIXER PCB 1
2
CN0720003801 CONNECTOR 1 TE5
2
CN0820001101 PARALLEL(8P WIRE) 1 TE1
2
CN1620002801 16P CONNECTOR 2 CON1,CON2
2
CS100J5005COG CAPACITOR 2 C38,40
2
CS101J5005COG CAPACITOR 100P SMD 28
C6,8,10,11,14,21,24,26,28,29,32,34~37,41
C42 45 60 63 65 68 160 163
2
CS102K5005X7R CAPACITOR 1000P SMD 2 C125,127
2
CS103K5005X7R CAP 0.01UF X7R 0805 1 C5
2
CS200J5005COG CAPACITOR 20P/50V SMD 78
C7,12,13,17,19,22,23,27,30,31,33,46,48
C51 69 87 96 99 102 105 132 134 136 138
2
CS331J5005COG CAPACITOR 30
C1~4,71,72,75,76,79,80,83,84,122~124,129~131
C429 432 441 445 447 449 451
2
CS470J5005COG CAPACITOR 47P SMD 5 C208,222,224,225,227
2
CS681J5005COG CERAMIC 68P 16 C52~59,433~440
2
DIENLL4148SM DIODE SMD ENLL4148SM 17 D9~21,38~41
2
EC10625T E.CAPACITOR 10UF/25V 17
C233,235,237,239,251,254,257,260,277,485
C487 489 491 497 500 503 506
2
EC10635TS CAPACITOR 1 C306
2
EC10710TS ELECTRIC CAPACITOR 16 C376~379,384~387,549~556
2
EC10806T ELECT ACP 1000UF/6.3V 8 C253,256,259,262,499,502,505,507
2
EC22450T CAPACITOR 16 C241~244,252,255,258,261,493~496,498,501,504,508
2
EC22450TS ELECTRIC CAPACITOR 8 C279,282,286,288,510,514,516,520
2
EC22550TS ELECTRIC CAPACITOR 9 C395~398,417,557~560
2
EC22616TS ELECT 5 C265,275,276,348,350
2
EC22710TS ELECT ACP 220UF/10V 16 C388~391,399~406,408~411
2
EC47625TS ELECT CAP 73
C232,245~250,263,264,266~274,278,280,281
C283 285 287 289 349 351 354 358 359 367
2
EC47650T ELECTRIC CAPACITOR 16 C228~231,234,236,238,240,481~484,486,488,490,492
2
IC4580L IC OP NJM 4580L 1 IC47
2
JK5031 XLR BASE 8 MIC1~8
2
JK6353-02-250 MIC BASE 29 J1~29
2
LD-LG2040 LED GREEN 12 LED3,4,11~14,16~21
2
LDLT0311-41 LED RED 15 LED2,7,9,22~29,38~41
2
LDLY2040A LED GREEN 17 LED5,6,8,10,15,30~37,42~45
2
LDU326V4M LED 1 LED1
2
MC12350TTF MALYER CAPACITOR 32
C293,297,301,305,316,318,320,322,324,326,328
C330 334 336 338 340 342 355 360 364 369 530
2
MC18350TTF CAPACITOR 32
C290~292,294~296,298~300,302~304,307~315
C317 319 321 521 528
2
MC33350TTF M.CAP 0.033UF/50V 32
C323,325,327,329,335,337,339,341,343~347
C356 357 361 363 365 366 368 370 371 373
2
MR249116 RESISTOR 2.49K 1/4W 16 R550~557,756~763
2
MR392116 RESISTOR 3.92K 1/16W 16 R566~573,772~779
2
MR680116 RESISTOR 6.8K 1/16W 16 R532~535,540,543,546,549,740~743,746,749,752,755
2
MR825016 RESISTOR 825 1/4W 16 R558~565,764~771
2
MT1305501 COLLAR SHAFT 21 -
2
PT111040105 LED 44 (LED2~45)
2
PT1310658 LAMP 1 (LED1)
2
R04716 RESISTOR 16
R538,539,541,542,544,545,547,548,744,745
R747 748 750 751 753 754
2
R18316T RESISTOR 2 R536,537
2
RJGJ107NI JACK 1 RCA1
2
RS04718J05 RESISTOR 8 R74,79,84,89,605,608,610,612
2
RS10018J05 RESISTOR 10Ω(SMD) 1 R136
2
RS10118J05 RES 100Ω 5% 0805 SMD 3 R270,394,395
2
RS10218F05 RESISTOR 8 R184,186,224,228,231,264,590,591
2
RS10318F05 RESISTOR 92
R5~11,23~26,28,36~43,45,47~49,59,60,90
R91 95 97 99 101 103 114 119 124 129 150
2
RS10418J05 RESISTOR 100K SMD 5 R388,392,488,495,524
2
RS10518J05 RES 1M 5% 0805 16 R272~275,277,279,282,286,672~675,308,309,311,344
