Alesis MultiMix FireWire 16 - Page 51

XF7ALE BOM
2
RS12118J05 RESISTOR 22
R4,12,13,15,16,21,27,29~33,63,64,68,69
R104 106 108 223 267
2
RS12318J05 RESISTOR 12K SMD 4 R472,473,491,493
2
RS13218F05 RESISTOR 13
R71,73,76,78,81,83,86,88,159,162,165,168,317
R607 614 616 618 619 621 622 633 635 637 639
2
RS15218J05 RESISTOR 26
R1,2,298,301,304,307,310,334,335,339,340,345,R348,350
R414 415 422 423 430 431 438 439 677 679 681 683
2
RS15318J05 RESISTOR 15K SMD 6 R61,67,468,486,499,515
2
RS18218J05 RESISTOR 1.8K SMD 2 R418,426
2
RS20318J05 RES 20K 5% 0805 32
R14,51,72,77,82,87,141~146,148,149,157
R160 163 166 492 501 502 505 517 518 604
2
RS22118F05 RESISTOR 1 R355
2
RS22218J05 RESISTOR 2.2K (SMD) 18
R17,34,158,161,164,167,169,171~176,178,640~643
2
RS22318J05 RESISTOR 22K(SMD) 14
R408,409,416,417,424,425,433,434,444,447
R448 449 496 498
2
RS22418J05 RESISTOR 1 R513
2
RS27218J05 RESISTOR 6 R179,182,459,461,463,465
2
RS27318J05 RESISTOR 27K(SMD) 28
R396,398,399,401,402,404,405,407,412,413
R420 421 428 429 436 437 446 466 522 528
2
RS27418F05 RESISTOR 16 R574~585,664~667
2
RS30218J05 RES 3K 5% 0805 2 R410,781
2
RS30318F05 RESISTOR 18 R50,65,115~118,120~123,125~128,130~133
2
RS33218J05 RESISTOR 2 R508,510
2
RS33318J05 RESISTOR 33K(SMD) 4 R58,96,519,526
2
RS33418J05 RESISTOR 1 R393
2
RS36218J05 RESISTOR 3.6K SMD 2 R351,390
2
RS39218J05 RESISTOR 3K9(SMD) 6 R226,266,319,322,325,328
2
RS43118F05 RESISTOR 1 R353
2
RS47118F05 RESISTOR 7 R134,135,154~156,352,354
2
RS47218J05 RESISTOR 4.7K SMD 56
R297,300,303,306,320,323,326,329,331,332,336,337
R341 342 346 347 358 363 368 373 376 378 379 381
2
RS47318J05 RESISTOR 47K 5% 0805 26
R356,359,362,364,367369,371,374,451,453,455
R457 489 497 704 707 709 711 713 715 732 735
2
RS51118F05 RESISTOR 510 (SMD) 16 R70,75,80,85,110~113,613,617,620,623~627
2
RS51218J05 RESISTOR 5.1K SMD 43
R19,20,44,46,52,66,287~292,313,315,397
R400 403 406 411 419 427 435 445 450 452
2
RS51318J05 RESISTOR 2 R490,494
2
RS56018J05 RESISTOR 56 (SMD) 1 R181
2
RS56118J05 RESISTOR 560Ω(SMD) 16
R193,196,199,202,204,206,209,212,214,217
R219 221 646 649 652 655
2
RS56218J05 RESISTOR 2 R520,521
2
RS56318J05 RESISTOR 56K SMD 4 R100,107,109,147
2
RS62118F05 RESISTOR 620 (SMD) 1 R316
2
RS62218J05 CAPACITOR 2 R18,35
2
RS62318J05 CAPACITOR 10 R137~140,389,391,628~631
2
RS68118J05 RESISTOR 1 R183
2
RS68218F05 CAPACITOR 37
R54~57,180,232,233,235,236,238,239,241
R242 244 247 249 251 254 256 259 261 280
2
RS75218F05 RESISTOR 5 R295,525,529~531
2
RS82118J05 RESISTOR 820Ω (SMD) 2 R271,293
2
RS82218F05 RES 8K2 5% 0805 8 R53,62,225,265,294,469,487,516
2
RS91118F05 RESISTOR 33
R170,177,191,192,194,195,197,198,200,201,203,205
R207 208 210 211 213 215 216 218 220 222 252 257
2
SC0306RIBI SCREW 21 -
2
SWSFPC12MC02 PUSH SWITCH 26 SW1~14,23,24,33~42
2
SWSFPC14MA01 PUSH SWITCH 24 SW15~22,25~32,43~50
2
TE162000602 TERMINAL 2 (TE3,4)
2
TE812000711 TERMINAL 1 (TE5)
2
TE812000811 CONNECTOR SOCKET 1 (TE1)
2
TR2SA970B6 TRANSISTOR 16 Q21~28,45~52
2
TRBC847B TRANSISTOR 32 Q1~8,10~17,29~44
2
TRBC857B TRANSISTOR 4 Q9,18~20
2
TRBF513 TRANSISTOR 4 FET1~4
2
VRK10301202 VR C10K 12 VR49~56,91~94
2
VRK1030904 VR 10KW 24 VR31~38,40~47,83~90
2
VRK5020902 VR 5KRD 8 VR1~4,67~70
2
VRK50301203 VR B50K X2 12 VR9~12,17~20,26~29
2
VRK50301204 VR B50K X2 3 VR30,39,48
2
VRK5030903 VR B50K 24 VR5~8,13~16,22~25,71~82
2
VRS10306007 CERAMIC 8 VR57~60,95~98
2
VRS10306008 CERAMIC 6 VR61~66
1
AL9-79-0404 P.C.BOARD ASS'Y 1 42
2
AL9-40-0404 PCB 1
2
TE612541801 CONNECTOR 14P 2 TE1,TE2
