Alesis MultiMix6FX Service Manual

2 CS104K2505X7R CERAMIC 0.1UF (SMD) 52
C7,11,20,21,24,25,27,31,34,37,45,46,55,56,57,58,59
,60,61,62,63,64,65,66,67,68,69,74,79,83,84,85,89,90
,94,95,98,99,102,103,104,105,108,109,110,111,112,
113,122,123,124,125
2 CS200J5005COG CERAMIC 20P (SMD) 35
C8,9,13,14,15,16,40,41,44,47,48,51,52,53,54,70,75,
86,87,88,91,92,93,96,97,100,101,106,107,114,116,1
17,118,120,121
2
CS331J5005COG
CERAMIC 330P (SMD) 12 C2,3,42,43,49,50,72,73,78,80,81,82
2
CS470J5005COG
CERAMIC 47P (SMD) 3 C71,115,119
2
CS681J5005COG
CERAMIC 680P (SMD) 4 C35,36,38,39
2
DIENLL4148SM
DIODE 8 D5,6,7,8,17,18,19,20
2
EC10616TS
ELECT 10UF/16V(S) 1 C242
2
EC10625T
ELECT 10UF/25V 4 C128,130,137,138
2
EC10635TS
ELECT 10UF/35V(S) 1 C157
2
EC10710TS
ELECT 100UF/10V(S) 4 C192,193,194,195
2
EC10806
ELECT 1000UF/6V 2 C135,136
2
EC22550TSU
ELECT 2.2UF/50V 2 C208,209
2
EC22616TS
ELECT 22UF/16V(S) 7 C143,144,145,188,189,190,191
2
EC22704T
ELECT 220UF/4V 8 C210,211,212,213,214,219,220,221
2 EC47625TS ELECT 47UF/25V(S) 32
C132,133,134,139,140,141,142,146,147,148,149,150
,151,152,181,183,198,199,202,203,204,205,206,207,
215,216,217,218,222,223,224,225
2
EC47650
ELECT 47UF/50V 4 C126,127,129,131
2
IC4580L
IC OP NJM 4508L 1 IC2
2
JK5031
XLR BASE 2 MIC1,2
2
JK6353-02-250
MIC BASE 14 J1,2,3,4,5,6,7,8,9,10,11,12,13,14
2
LD-LG2040
GREEN LED 6 LED2,3,9,10,11,12
2
LDLT0311-41
RED LED 5 LED1,5,6,13,14
2
LDLY2040A
YELLOW LED 3 LED4,7,8
2
MC12350T
CAP 0.012UF/50VJ 12 C164,167,168,170,171,173,174,175,176,177,178,179
2
MC18350T
CAP 0.018UF/50VJ 12 C153,154,155,156,158,159,160,161,162,163,165,166
2
MC33350T
CAP 0.033UF/50VJ 12 C169,172,180,182,184,185,186,187,196,197,200,201
2
MR249216
RESISTOR 2.49K 4 R260,261,262,263
2
MR392216
RESISTOR 3.92K 4 R268,269,270,271
2
MR681216
RESISTOR 6.8K 4 R250,251,256,257
2
MR825116
RESISTOR 825O 4 R264,265,266,267
2
5-03-0036
STANDOFF METAL F-F 13.5MM M3 6
2
RJGJ107NI
JACK 1 RCA1
2
RS00018J05
RESISTOR 0O (SMD) 4 R207,212,213,223
2
RS04718J05
RESISTOR 4.7O (SMD) 2 R39,40
2
RS10018J05
RESISTOR 10O (SMD) 1 R294
2
RS10118J05
RESISTOR 100O (SMD) 2 R191,197
2
RS10218F05
RESISTOR 1K (SMD) 1% 6 R113,114,126,132,136,142
2
RS10318F05
RESISTOR 10K (SMD)1% 4 R19,20,37,38
2 RS10318J05 RESISTOR 10K (SMD) 34
R5,7,8,12,15,18,24,25,26,42,46,49,54,56,58,59,62,6
3,102,104,143,144,151,153,162,163,194,196,204,20
8,222,226,227,233
2
RS10418J05
RESISTOR 100K (SMD) 4 R152,154,214,230
2
RS10518J05
RESISTOR 1M (SMD) 6 R169,170,174,180,184,185
2
RS12118J05
RESISTOR 120O (SMD) 14 R3,4,6,9,11,13,27,29,30,33,41,43,52,55
2
RS13218J05
RESISTOR 1K3 (SMD) 4 R47,48,50,51
2
RS15218J05
RESISTOR 1K5 (SMD) 6 R205,206,218,219,224,225
2
RS15318J05
RESISTOR 15K (SMD) 5 R53,242,246,247,249
2
RS20218F05
RESISTOR 2K (SMD)1% 1 R190
2
RS20318J05
RESISTOR 20K (SMD) 10 R10,72,85,86,88,89,98,99,167,168
2
RS22118J05
RESISTOR 220O (SMD) 1 R195
2
RS22218F05
RESISTOR 2K2 (SMD) 11 R1,17,32,44,91,97,100,101,106,107,187
2
RS24218J05
RESISTOR 2K4 (SMD) 2 R172,182
2
RS27218J05
RESISTOR 2K7 (SMD) 3 R110,111,164
2
RS27318J05
RESISTOR 27K (SMD) 2 R243,245
2
RS30318J05
RESISTOR 30K (SMD) 10 R16,68,69,70,71,73,74,75,76,77
2
RS36218J05
RESISTOR 3K6 (SMD) 4 R166,171,228,232
