Alesis MultiMix6FX Service Manual

2
RS39218J05
RESISTOR 3K9 (SMD) 4 R120,137,175,179
2
RS43218J05
RESISTOR 4K3 (SMD) 2 R177,178
2
RS47118J05
RESISTOR 470O (SMD) 5 R80,81,83,84,90
2
RS47218J05
RESISTOR 4K7 (SMD) 12 R31,36,57,61,173,176,198,200,237,238,239,248
2
RS47318J05
RESISTOR 47K (SMD) 3 R189,192,193
2
RS51118J05
RESISTOR 510O (SMD) 4 R64,65,66,67
2 RS51218J05 RESISTOR 5K1 (SMD) 25
R21,22,23,34,35,82,87,161,165,186,188,199,203,21
0,211,215,216,229,231,234,235,236,240,241,244
2
RS56018J05
RESISTOR 56O (SMD) 1 R105
2
RS56118J05
RESISTOR 560O (SMD) 6 R121,125,127,128,138,139
2
RS56218J05
RESISTOR 5K6 (SMD) 1 R28
2
RS56318J05
RESISTOR 56K (SMD) 2 R45,60
2
RS62218J05
RESISTOR 6K2 (SMD) 2 R2,14
2
RS68118J05
RESISTOR 680O (SMD) 1 R103
2 RS68218J05 RESISTOR 6K8 (SMD) 16
R92,112,145,146,147,148,149,150,155,156,157,158,
159,160,220,221
2
RS82218F05
RESISTOR 8K2 (SMD)1% 5 R134,141,181,209,217
2
RS91118J05
RESISTOR 910O (SMD) 12 R109,115,116,117,119,122,123,129,130,131,133,135
2
R004716
RESISTOR 0.47O 1/16W 4 R252,253,254,255
2
R18316
RESISTOR 18K 1/16W 2 R258,259
2
SC0306RIBI
SCREW 6
2
SWSFPC12MC02
PUSH SWITCH 6 SW1,2,3,4,5,6
2
TE162000602
6P TERMINAL 2 TE2,3
2
TE812000811
8P CONNECTOR 1 TE1
2
TRA1316GR
TRANSISTOR 2SA1316GR 4 Q12,13,14,15
2
TRBC847B
TRANSISTOR 8 Q1,2,3,4,8,9,10,11
2
TRBC857B
TRANSISTOR 3 Q5,6,7
2
VRK10301202
VR 10K AC CC 4 VR22,23,24,25
2
VRK10301207
VR 10KK(25A) 1 VR16
2
VRK10301209
VR B10K X2 4 VR28,29,30,31
2
VRK1030904
VR 10KW 4 VR17,18,19,20
2
VRK1030905
VR 10KB 2 VR26,27
2
VRK5020902
VR 5KRD 2 VR1,2
2
VRK50301203
VR B50K X2 CC 6 VR5,6,10,11,14,15
2
VRK50301204
VR 50RW X2 1 VR21
2
VRK5030903
VR B50K 6 VR3,4,8,9,12,13
2
0-16-1472
RESISTOR 14.7K (SMD) 4 R108,118,124,140
2
0-16-6041
RESISTOR 6.04K (SMD) 2 R78,79
2
0-16-7321
RESISTOR 7.32K (SMD) 4 R93,94,95,96
2
0-16-7501
RESISTOR 7.5K (SMD) 1 R183
2
2-71-0084
IC 1 IC14
2
2-71-4580
IC 19 IC3,4,5,6,7,8,9,12,15,16,17,20,21,22,23,24,25,26,27
2
2-72-0339
IC LM339 3 IC13,18,19
2
2-75-1101
IC AL1101 1 IC10
2
2-75-1201
IC AL1201 1 IC11
2
2-99-0021
DIODE BAV21 4 D1,2,3,4
2
6-00-0008
ENCODER 1 VR7
1
9-79-0302
MICON PCB ASS'Y 1
24
2
CC10450T
CERAMIC 0.1UF 1 C229
2
CS104K2505X7R
CERAMIC 0.1UF (SMD) 3 C226,227,228
2
LDT2601G
LED SENSOR 1 LED15
2
RS10118J05
RESISTOR 100O (SMD) 3 R272,285,286
2
RS22118J05
RESISTOR 220O (SMD) 8 R277,278,279,280,281,282,283,284
2
RS47118J05
RESISTOR 470O (SMD) 4 R273,274,275,276
2
TE162000601
6P TERMINAL 2 TE4,5
2
TE162500603
8P TERMINAL 1 TE6
2
TRBC857B
TRANSISTOR 2 Q16,17
2
2-27-0054
IC AL3201 1 IC28
2
ICAL2K03M01
IC 87C84 64K 1 IC29
2
7-01-0033
CRYSTAL 12MHz 1 M1
