Alesis MultiMix6FX Service Manual

1
9-79-0304
POWER PCB ASS'Y 1
15
2
CS104K2505X7R
CERAMIC 0.1UF (SMD) 2 C230,231
2
DIN4002
DIODE 8 D9,10,11,12,13,14,15,16
2
DIZBZX79C47V
ZENER DIODE 1 R290
2
EC107100TS
ELECT 100UF/100V(S) 1 C241
2
EC10735T
ELECT 100UF/35V 1 C232
2
EC10835
ELECT 1000UF/35V 2 C233,234
2
EC476100
ELECT 47UF/100V 2 C237,238
2
EC47625
ELECT 47UF/25V 2 C235,236
2
EC47650
ELECT 47UF/50V 2 C239,240
2
IC7805
IC 1 IC30
2
IC7815
IC 1 IC32
2
IC7915
IC 1 IC31
2
JW5206T
JUMP WIRE 1 R288
2
R10014
RESISTOR 10O 1/4W 1 R293
2
R10318
RESISTOR 10K 1/8W 1 R289
2
R20314
RESISTOR 20K 1/4W 1 R292
2
R39414
RESISTOR 390K 1/4W 1 R291
2 TE612000202 2P CONNECTOR
1
TE10
2 TE612000301 3P CONNECTOR
1
TE7
2
TE612000402
4P CONNECTOR 1
TE8
2
TE612000801
8P CONNECTOR
1
TE9
2
TRBD239C
TRANSISTOR
1
IC33
