Below is a reference chart of all available modes for the knobs, slider, accelerometer, and ribbon controller, as well as
the available parameters that can be edited for these controls.
Mode Assigned Knob Function
CC Message
Knob #1 CC # (0 – 127)
Knob #2 Range Min (0 – 127)
Knob #3 Range Max (0 – 127)
Pitch Bend
Knob #1 MIDI Channel (1 – 16)
Knob #2 Range Min (0 – 127)
Knob #3 Range Max (0 – 127)
Aftertouch
Knob #1 MIDI Channel (1 – 16)
Knob #2 Range Min (0 – 127)
Knob #3 Range Max (0 – 127)
Editing the Pitch Wheel
To edit the orientation of the pitch-bend wheel:
1. Press Patch Edit.
2. Move the pitch-bend wheel. Pth will display on the LED display screen.
3. Press the Mode Assign key.
4. Choose Pc1 for the original orientation, or choose Pc2 to reverse the original orientation of the pitch-bend
wheel.
5. Press the Enter key to save the changes or the Cancel key to revert to the original setting.
Editing the Start/Stop Button
The Start/Stop button can be set to Realtime Mode, or CC Mode. In Realtime mode, the Start/Stop button will toggle
between sending system realtime start and stop messages. In CC Mode, the Start/Stop button will toggle between
two CC messages.
To edit the Start/Stop button mode and parameters:
1. Press the Patch Edit button.
2. Press the Start/Stop Button.
3. Press Mode Assign.
4. Set the mode (1 – 2) using the numeric keys. Alternatively, press Mode Assign to cycle between modes.
Note: The LED display screen will display rt (for Realtime Mode), or CC (for CC Mode).
5. Use the 3 knobs to change parameter values and select the mode.
Note: After moving the corresponding knob, you can use the numeric keys to enter a value.
6. Press the Enter key to save the changes or the Cancel key to revert to original settings.
To Next Page
