Alex CF 1801 - Assembly Instruction

10
10
31
10
10
31
10
10
10
31
50
50
51
ASSEMBLY INSTRUCTION
●STEP ONE: Assemble the posts
First, connect the cable (64) with (65) in the right post（3）,
Second, lift the side posts and place them in correspondence to the pre-drilled holes on the base frame;
use the supplied screws（11） and washers (24) and (29) to fix the side post to the base frame.
7
