WARNING! : Use extreme caution when assembling the treadmill. Failure to do so could result in injury
NOTE: Each step number in the assembly instructions tells you what you will be doing. Read and
understand all instructions thoroughly before assembling the treadmill.
1. Unpack the carton and take out all loose parts etc and place outside of the carton.
2. Tear open the carton as shown in the picture below and then fold up the treadmill.
3. Hold on roller cover by two hands and lean back the treadmill, move the treadmill forward as the picture
shows.
Item No.
DESCRIPION
SPEC
UNITS
QTY
1
Base Frame
SET
1
2
Left console mast
SET
1
3
Right console mast
SET
1
4
Main frame
SET
1
5
Motor frame
SET
1
6
Console Frame
SET
1
7
Large flat head screws Hexagon
M8*15 UCP
PCS
6
8
Large flat head screws Hexagon
M8*30 15 UCP
PCS
3
9
Large flat head screws Hexagon
M8*42 28 UCP
PCS
1
10
Large flat head screws Hexagon
M8*50 20 UCP
PCS
2
11
Large flat head screws Hexagon
M8*60 20 UCP
PCS
4
12
Hexagon screw
M8*65 UCP
PCS
1
13
Hexagon screw
M8*80 UCP
PCS
2
14
Hexagon screw
M8*20 UCP
PCS
1
15
Hexagon screw
M10*25 UCP
PCS
4
