Alienware AW2524HF - VESA wall mounting (optional)

38 | Setting up the monitor
VESA wall mounting (optional)
NOTE: Use M4 x 10 mm screws to connect the monitor to the wall-
mounting kit.
Refer to the instructions that come with
the VESA-compatible wall-mounting kit.
1. Plac
e the monitor panel on a soft cloth or cushion on a stable flat surface.
2. Remove
the monitor stand. (See Removing the monitor stand.)
3. Us
e a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4. Attach the
mounting bracket from the wall-mounting kit to the monitor.
5. M
ount the monitor on the wall. For more information, see the
documentation that shipped with the wall-mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with
minimum weight or load bearing capacity of 14.60 kg.
