24 | About your monitor
Universal Serial Bus (USB) interface
This section provides information about the
USB ports that are available on the
monitor.
NOTE: This monitor is SuperSpeed USB 5 Gbps (USB 3.2 Gen 1)
compatible.
*Up to 2 A on USB downstream port (with battery icon) with battery
charging version-compliant devi
ces or normal USB devices.
USB 3.2 Gen 1 (5 Gbps) upstream connector
Transfer speed Data rate Power consumption*
Super-Speed 5 Gbps 4.50 W (maximum each port)
High speed 480 Mbps 4.50 W (maximum each port)
Full speed 12 Mbps 4.50 W (maximum each port)
Pin number Signal name
1VBUS
2D-
3D+
4GND
5StdB_SSTX-
6StdB_SSTX+
7GND_DRAIN
8StdB_SSRX-
9StdB_SSRX+
Shell Shield
