MAIN Unit MAIN Unit
Ref No Parts No. Description Parts Name Ver Ref No Parts No. Description Parts Name Ver Ref No Parts No. Description Parts Name Ver Ref No Parts No. Description Parts Name Ver
JK2 UE0190 Connector ANT Cable R1 RK0108 Chip R. ERJ6GEYJ2R2V R55 RK3050 Chip R. ERJ3GSYJ103V R111 - 1.2
JK4 UJ0024 Connector SJ1403JDIJ010 R2 RK2024 Chip R. MCR50JZHJ471 R56 RK3050 Chip R. ERJ3GSYJ103V R112 RK3049 Chip R. ERJ3GSYJ822V
L1 QC0063 Coil NL322522TJ047M R3 RK3050 Chip R. ERJ3GSYJ103V R57 RK3018 Chip R. ERJ3GSYJ220V 0 R113 RK3050 Chip R. ERJ3GSYJ103V
L2 QC0063 Coil NL322522TJ347M R4 RK307l Chip R. ERJ3GSYJ564V RK3026 Chip R. ERJ3GSYJ101V 1,2 R114 RK3062 Chip R. ERJ3GSYJ104V
L3 QC0048 Coil NL322522T-100K R5 RK3034 Chip R. ERJ3GSYJ471V R58 RK3038 Chip R. ERJ3GSYJ102V R115 RK3038 Chip R. ERJ3GSYJ102V
L4 QA0084 Coil 0,1 R6 RK3062 Chip R. ERJ3GSYJ104V R59 RK3053 Chip R. ERJ3GSYJ183V R116 RK3023 Chip R. ERJ3GSYJ560V
QA0100 Coil 2 R7 RK3042 Chip R. ERJ3GSYJ222V R60 RK3034 Chip R. ERJ36SYJ471V R121 - 0,1
L5 QA0084 Coil 0,1 R8 RK3042 Chip R. ERJ3GSYJ222V R61 RK3038 Chip R. ERJ3GSYJ102V RK3001 Chip R. ERJ3GSYJ000V 2
QA0100 Coil 2 R9 RK3001 Chip R. ERJ3GSYJ000V R62 RK3054 Chip R. ERJ3GSYJ223V R122 - 0
L6 QA0084 Coil 0,1 R10 RK3071 Chip R. ERJ3GSYJ564V R63 RK3032 Chip R. ERJ3GSYJ331V RK3030 Chip R. ERJ3GSYJ221V 1.2
QA0100 Coil 2 R11 RK3046 Chip R. ERJ3GSYJ472V R64 RK3042 Chip R. ERJ3GSYJ222V l R123 RK3038 Chip R. ERJ3GSYJ102V
L7 QC0067 Coil N L322522T-R10M R12 RK3038 Chip R. ERJ3GSYJ102V R65 RK3026 Chip R. ERJ3GSYJ101V R130 RK3058 Chip R. ERJ3GSYJ473V 0
L8 QC0063 Coil N L322522T-047M R13 RK3038 Chip R. ERJ3GSYJ102V R66 RK3050 Chip R. ERJ3GSYJl03V - 1.2
L9 QKA45E Coil MR 3.0 4.5 T 0.8 R14 RK3071 Chip R. ERJ3GSYJ564V R67 RK3026 Chip R. ERJ3GSYJ101V R131 RK3042 Chip R. ERJ3GSYJ222V 2
L10 QKA45E Coil MR 3.0 4.5 T 0.8 R15 RK3050 Chip R. ERJ3GSYJ103V R68 RK3030 Chip R. ERJ3GSYJ221V TCl CT0012 Trimmer CTZ-10AW
L11 QKA45E Coil MR 3.0 4.5 T 0.8 R16 RK4028 Chip R. ERJ-12YJ151 R69 RK3050 Chip R. ERJ3GSYJ103V TH1 XS0012 Thermistor TD5-C220DH
L12 QKA35D Coil R17 RK3057 Chip R. ERJ3GSYJ393V R70 RK3051 Chip R. ERJ3GSYJ123V TH2 XS0013 Thermistor TD5-C2680DH
R18 RK3042 Chip R. ERJ3GSYJ222V R71 RK3026 Chip R. ERJ3GSYJ101V VR1 RH0106 Trim. Pot EVM1YSX50BQ4
L13 QKA95D Coil MR3.09.5T0.6 R19 RK3060 Chip R. ERJ3GSYJ683V R73 RK3052 Chip R. ERJ3GSYJ153V VR2 RH0103 Trim. Pot EVMIYSX50B14
L14 QA0084 Coil 0,1 R20 RK3060 Chip R. ERJ3GSYJ683V R74 RK3052 Chip R. ERJ3GSYJ153V VR4 RH0060 Trim. Pot MVR32HXBRN473
QA0100 Coil 2 R21 RK3051 Chip R. ERJ3GSYJ123V R75 RK3052 Chip R. ERJ3GSYJ153V VR5 RH0106 Trim. Pot EVM1YSX50BQ4
L15 QC0067 Coil N L322522T-R10M R22 RK3050 Chip R. ERJ3GSYJ103V R76 RK3026 Chip R. ERJ3GSYJ101V VR6 RH0061 Trim. Pot MVR32HXBRN472
L16 QKA35D Coil MR3.03.5T0.6 R23 RK3050 Chip R. ERJ3GSYJ103V R77 RK3050 Chip R. ERJ3GSYJ103V X1 XQ0054 Crystal X49U-12.8MHz
M106 SD0034 Earth Spdrg DR130 R24 RK3050 Chip R. ERJ3GSYJ103V R78 RK3026 Chip R. ERJ3GSYJ101V X2 XK0002 Discrinbnator CDBM455C7
Q1 XE0012 FET 3SK131V11. 12T1 R25 RK3047 Chip R. ERJ3GSYJ562V R79 RK3038 Chip R. ERJ3GSYJ102V X3 XQ0059 Crystal X49U-16.745MHz
Q2 XE0012 FET 3SK131V11. 12T1 RK3046 Chip R. ERJ3GSYJ472V 2 R80 RK3050 Chip R. ERJ3GSYJ103V TS0092 VC0 Shield
Q3 XT0094 Transistor 2SA1576 T106R R26 RK3026 Chip R. ERJ3GSYJ101V R81 RK3052 Chip R. ERJ3GSYJ153V TT1001 Tube 0.7 1mm x 6
Q4 XT0095 Transistor 2SC4081 T106R R27 RK3038 Chip R. ERJ3GSYJ102V R82 RK3038 Chip R. ERJ3GSYJ102V TZ0049 Silicon Dumper
Q5 XT0095 Transistor 2SC408l T106R R28 RK3058 Chip R. ERJ3GSYJ473V R83 RK3022 Chip R. ERJ3GSYJ470V TZ0056 Silicon Dumper 49U
Q6 XT0095 Transistor 2SC4081 T106R R29 RK3042 Chip R. ERJ3GSYJ222V R84 RK3034 Chip R. ERJ3GSYJ471V YZ0001 Silicon Grease G746
Q7 XT0061 Transistor 2SB1132 T100Q R30 RK3045 Chip R. ERJ3GSYJ392V R85 RK3043 Chip R. ERJ3GSYJ272V
Q8 XT0096 Transistor 2SC4099 T106N R31 RK3054 Chip R. ERJ3GSYJ223V R86 RK3045 Chip R. ERJ3GSYJ392V
Q9 XT0037 Transistor 2SC2412K T146R R32 RK3057 Chip R. ERJ3GSYJ393V R88 RK3014 Chip R. ERJ3GSYJ100V
Q10 XU0131 Transistor DTC114EU T106 R33 RK3038 Chip R. ERJ3GSYJ102V R89 RK0028 Chip R. ERJ6GSYJ471V
Qll XU0148 Transistor DTC144EU T106 R34 RK4018 Chip R. ERJ-12YJ220 R91 RK3001 Chip R. ERJ3GSYJ000V
Q12 XU0112 Transistor DTA114YU T106 R35 RK3050 Chip R. ERJ3GSYJ103V R92 RK3038 Chip R. ERJ3GSYJ102V
Q13 XT0112 Transistor 2SBl292F R36 RK3038 Chip R. ERJ3GSYJ102V R93 RK3062 Chip R. ERJ3GSYJ104V
Q14 XT0095 Transistor 2SC408l T106R R37 RK3045 Chip R. ERJ3GSYJ392V R94 RK3050 Chip R. ERJ3GSYJ103V
Q15 XT0084 Transistor 2SC2954-Tl R38 RK3054 Chip R. ERJ3GSYJ223V R96 RK3071 Chip R. ERJ3GSYJ564V
Q16 XT0095 Transistor 2SC408l Tl06R R39 RK3032 Chip R. ERJ3GSYJ331V R98 RK0069 Chip R. ERJ6GSYJ104V
Q17 XU0152 Transistor UMC5TR R40 RK3054 Chip R. ERJ3GSYJ223V R99 RK3052 Chip R. ERJ3GSYJ153V
Q18 XE0001 Transistor 2SK880GR TE85L R41 RK3042 Chip R. ERJ3GSYJ222V R100 RK3044 Chip R. ERJ3GSYJ332V
Q19 XT0114 Transistor 2SC4403 R42 RK3041 Chip R. ERJ3GSYJ182V R101 RK3052 Chip R. EFU6GSYJ153V 0
Q20 XT0030 Transistor 2SCX3BB6-T1 R43 RK3058 Chip R. ERJ3GSYJ473V 0 RK0039 Chip R. ERJ6GSYJ222V l,2
Q2l XT0099 Transistor 2SA1736Y TEl2L RK3055 Chip R. ERJ3GSYJ273V 2 R102 RK3038 Chip R. ERJ3GSYJ102V 0
Q22 XT0095 Transistor 2SC4081 T106R R44 RK3014 Chip R. ERJ3GSYJ100V RK3046 Chip R. ERJ3GSYJ472V l.2
Q24 XU013l Transistor DTCl14EUTl06 R45 RK3026 Chip R. ERJ3GSYJ101V R103 RK3026 Chip R. ERJ3GSYJ101V
Q30 XU0148 Transistor DTC144EU R46 RK3001 Chip R. EFU3GSYJ000V R104 RK3050 Chip R. ERJ3GSYJ103V
R47 RK3062 Chip R. ERJ3GSYJ104V R105 RK3042 Chip R. ERJ3GSYJ222V
R48 RK3026 Chip R. ERJ3GSYJ10lV R106 RK3062 Chip R. ERJ3GSYJ104V 0 : T/E/EZ/EA/TA
R49 RK3038 Chip R. ERJ3GSYJ102V R107 RK0001 Chip R. ERJ6GSYJ100V 1: TE1
R50 RK3071 Chip R. ERJ3GSYJ564V R108 RK3043 Chip R. ERJ3GSYJ272V 2: TE2
R51 RK3054 Chip R. ERJ3GSYJ223V R109 RK3062 Chip R. ERJ3GSYJ104V None: all models page-23
R53 RK3044 Chip R. ERJ3GSYJ332V R111 RK3001 Chip R. ERJ3GSYJ000V 0
R54 RK4034 Chip R. ERJ-12YJ471
