1. Select temperature (if so equipped).
2. With the gun assembly in hand (on trigger gun
models hold the trigger gun valve in open
position) and with a good flow of water start
the engine per engine owner’s manual.
CAUTION: A good flow of water must be Flowing
from the end of a gun for 30 seconds, before
proceeding. Lack of water can cause damage to
the water pump and like components.
CAUTION: On a machine equipped with a
trigger gun valve, if the trigger gun valve
remains in the closed position
for more than 3 minutes, water pump damage
may occur.
4. Turn the burner switch on.
CAUTION: Do not run the machine with the
burner switch in the on position when the fuel
tank is empty or with tank valves closed. This
will cause damage to the fuel pump and
void warranty.
CAUTION: Do not operate with the trigger gun
valve closed for more than 3 minutes or water
pump damage may occur.
5. To CLEAN:
A. Start on the lower portion of the area to be
cleaned and work up using long, even,
overlapping strokes.
B. Dirt is generally removed easily if grease
and/or oil is not present. However if grease
and/or oil are present, hot water and
chemical will accelerate in the cleaning
process.
6. TO APPLY CHEMICAL:
CHEMICAL: Use factory recommended
chemicals for best cleaning action and for
extended pump life. Contact your dealer for
chemicals available. Follow instructions on
chemical container.
Mix chemicals per label instructions. Use
necessary safety precautions.
A. Insert chemical screen into chemical
container
B. Adjust metering valve (if so equipped).
C. If the gun assembly is equipped with
variable or multiple nozzle assembly,
adjust as desire.
7. TO RINSE:
A. If the machine is equipped with a panel
mounted metering valve, close the chemical
metering valve (if so equipped). NOTE: It is
advisable to dip the chemical screen in a
container of clean water and open the valve
1 minute to clean the valve of any remaining
residue.
B. If the gun assembly is equipped with variable
or multiple nozzle assembly, open and close to
clean nozzle of any remaining residue.
C.After a clear flow of water is noted from the
end of the wand, start from the top, working
downward using long, overlapping strokes.
SHUT-DOWN
1. Turn the burner switch to the off position. (If
not already done so in the cold water rinse.)
2. After cool, clear water is coming from the end
of the wand, turn off the engine.
3. Turn off the water supply.
4. If freezing conditions may exist, refer to
STORAGE in MACHINE MAINTENANCE.
5. Replace stack cover (if so equipped).
11-07-03 Z08-00489D
7
ECN-03022 Supersedes 06-06-01 Z08-00489
WARNING: RISK OF INJECTION OR SEVERE
INJURY. KEEP CLEAR OF NOZZLE. DO
NOT DIRECT DISCHARGE STREAM AT
PERSONS. THIS EQUIPMENT IS TO BE
USED ONLY BY TRAINED
OPERATORS.
AVERTISSEMENT:RISQUE
D’INJECTION ET DE BLESSURES GRAVES.
SE TENIR À L’ÉCART DU JET. NE PAS
DIRIGER LE JET DE SOTIE VERS D’AUTRES
PERSONNES CONFIER L’UTILISATION LE
JET DE SOTIE VERS D’AUTRES
PERSONNES. CONFIER L’UTILISATION DE
CE MATÉRIEL À UN OPÉRATEUR QUALIFIÉ.
