Part No. Description
Bottom only (specify size and with or without parts)
Cover only (specify size and with or without parts)
54 Clamp Bolt (630000) (3/8=16 x 1-25/32)
55 Pin for Clamp Bolt (630010)
64 Wing Nut (630020)
65 DISCONTINUED — Replaced by # 65K
65K Tested Control Valve (releases at 23-28 psi) (Z000207) (1/8"NPT) Replaces #65
72S Tested Steam Gauge - includes lens (Z000128) (1/8" NPT)
75 (Replaced by No. 2050K) Excess Pressure Release Plug (not shown)
76 Bakelite Top Handle (No Longer Available) – Order Part Number 76-09 RM
76-09 RM Handle w/Screws (New Handle to Replace Old Style #76 with Screws-See Picture) Z000198
76-09 Handle w/Screws (New Style Handle-See Picture) Z000187
77-09 Top Handle Screw (New Style only) 630077)
78 Retaining Bayonet Clamp (630090)
79 Bayonet Clamp Screw (670020)
111 Rack (For inside Aluminum Container for 1915X, 1925X) (630110) (9 1/2" Diameter)
151 Rack (For inside Aluminum Container for 1941X) (630120) (11 1/2" Diameter)
405 Side Handle Complete (with screws, for 1941X) (Z000113)
1010 Overpressure Plug (For Sterilizer - Red Color) (Z000123)
2050K (2050CS DISCONTINUED – Replaced by 2050K) Pressure Relief Valve (releases as 28 psi) (640185) (1/8"NPT)
2155-15 Exhaust Tube 1915X (640210) (7 1/4 inches long)
2155-25 Exhaust Tube 1925X (640220) (10 3/4 - 11 inches long)
2155-41 Exhaust Tube 1941X (640230) (14 3/4 inches long)
2162 Aluminum Container for 1925X (640070)
2163 Aluminum Container for 1915X (640080)
2164 Aluminum Container for 1941X (640090)
*6054 Dual Scale Thermometer (C Scale: 10 -150 , F Scale: 50 -300) (640140)
*Factory Installation Fee for Thermometer
* We recommend that the Thermostat, Thermoswitch, Heating Element and Thermometer be replaced at the factory.
NO GUARANTEE OR REASONABILITY FOR THE PROPER FUNCTIONING OF THESE PARTS CANNOT BE ASSUMED BY
THE COMPANY IF THEY ARE NOT INSTALLED AT THE FACTORY.
ALL-AMERICAN NON-ELECTRIC
STEAM PRESSURE STEAM STERILIZERS PARTS LIST
FOR MODELS 1915X, 1925X AND 1941X
