3
Brief introduction
EM1230 is a 25MHz digital storage oscilloscope,6000 words True RMS
Digital Multimeter functions integrated multifunctional handheld instrument, ideal for field use.
The main function
2-channel ,25MHz digital storage oscilloscope
True 6000 words RMS digital multimeter
Features
100MSa / s real-time sampling rate, 25MHz real-time bandwidth
Automatic tracking measurement: automatic tracking based on external input signal to
adjust the vertical amplitude \ horizontal time base and trigger stalls, without human
intervention
Large
dynamic measurement range: no extended probe leads directly measure range from
10mV/div to 500V/div
Screen can display 4 measurement parameters the user can choose RMS, peak, average,
frequency, period, in 22 kinds of parameters as needed, etc.
Two kinds of cursor measurement mode selection
320 * 240 dot TFT LCD,
Built-in battery, AC and DC
Recorder --- continuous track record up to 12 hours of event
Standard USB interface, through the PC software can easily communicate with a computer
for data analysis and test results archive
UserEM1230
Handheld Digital Oscilloscope
,
s Manual
