Chapter I.Recognizing this product
EM1230
Handheld Digital Oscilloscope User
,
s Manual
1 Product Description
1.1 Front Pane
The Product is a handheld portable products, AC and DC power supply, 3.7V lithium battery
inside the instrument; external AC-DC adapter with 220/5V can provide external power and
charge the lithium battery inside the instrument instrument
Side port
AC-DC adapter
Power
j
ack and USB
320×240 TFT
LCD screen
Measurement
port
Panel and
function keys
Handle
