ALLEN & HEATH DX168 User Manual

DX168 Getting Started Guide
AP11129 Issue 2
Specification
Mic/Line XLR Inputs
Balanced XLR, +48V phantom power
Mic/Line Preamp
Fully recallable
Input Sensitivity
-60 to +15dBu
Analogue Gain
+5 to +60dB, 1dB steps
Pad
-20dB Active PAD
Maximum Input Level
+30dBu (PAD in)
Input Impedance
>4kΩ (Pad out), >10kΩ (Pad in)
Mic EIN
-127dB with 150Ω source
Analogue XLR Outputs
Balanced, Relay protected
Output Impedance
<75Ω
Nominal Output
+4dBu = 0dB meter reading
Maximum Output Level
+22dBu
Residual Output Noise
-92dBu (muted, 20-20kHz)
Operating Temperature Range
0°C to 40°C (32°F to 104°F)
Power
Mains Voltage Operating Range
100-240V AC, 50/60Hz
Mains Power Consumption
20W max
Dimensions and Weight
Width x Depth x Height x Weight
DX168
410 x 190 x 185 mm x 4.6kg
(16.1” x 7.5” x 7.3” x 10.1lbs)
Read the Safety Instructions Sheet included with the product and the information printed on the panel before operating.
A limited one year manufacturer’s warranty applies to this product, the conditions of which can be found at:
www.allen-heath.com/legal
By using this Allen & Heath product and the software within it you agree to be bound by the terms of the relevant End
User Licence Agreement (EULA), a copy of which can be found at: www.allen-heath.com/legal
Register your product with Allen & Heath online at: http://www.allen-heath.com/support/register-product/
Check the Allen & Heath website for the latest documentation and software updates
ALLEN&HEATH
Copyright © 2018 Allen & Heath. All rights reserved

ALLEN & HEATH DX168 Specifications

General

Sample Rate	96 kHz
Bit Depth	24-bit
Inputs	16
Outputs	8
Power Supply	100-240V AC, 50/60 Hz
Type	Audio Expander
Channels	16 in, 8 out
Compatibility	Allen & Heath dLive, Avantis
AD/DA Conversion	24-bit
