23 WZ16:2DX AND WZ12:2DX USER GUIDE
FX types available:
This table shows the effects types available. You may change the factory defaults to other types shown here using the Allen & Heath MixWizard FX Editor software running
on a PC.
Parameters
1 2 3 4 FX
Type
Description H or W
type*
ID
Code
Name Range Name Range Name Range Name Range
CH Chorus H 12 Speed 1-99 Depth 0-40 Delay 0-40ms Level 0-99
FL Flanger H 14 Speed 1-99 Depth 0-40 Feedback 0-97% Level 0-99
PH Phaser H 16 Speed 1-99 Depth 0-40 Feedback 0-97% Level 0-99
Tr Tremelo H 18 Speed 1-99 Depth 0-40 N/A - Level 0-99
Pn Panner H 20 Speed 1-99 Depth 0-40 N/A - Level 0-99
RS Rotary Spkr W 24 Speed 1-99 Type 6 variants X-over freq Level 0-99
PS Pitch Shift H 34 Shift -12 to +24 Tracking 1-3 N/A - Level 0-99
Dn Detuner H 36 Detune -12 to +12 N/A - N/A - Level 0-99
St Stage W 84 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
St Stage H 66 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
Ro Room W 86 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
Ro Room H 68 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
HA Hall W 88 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
HA Hall H 70 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
PL Plate W 90 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
PL Plate H 72 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
Ch Chamber W 92 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
Ch Chamber H 74 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
CA Cathedral W 94 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
CA Cathedral H 76 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
Ar Arena W 96 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
Ar Arena H 78 Predelay 0-99ms Decay 1-10 Damping 1-10 Level 0-99
GA Gated H 62 Predelay 0-99ms Decay 1-10 Diffusion 1-10 Level 0-99
GA Gated W 80 Predelay 0-99ms Decay 1-10 Diffusion 1-10 Level 0-99
RE Reverse H 64 Predelay 0-99ms Decay 1-10 Diffusion 1-10 Level 0-99
RE Reverse W 82 Predelay 0-99ms Decay 1-10 Diffusion 1-10 Level 0-99
Rg Ring Modulator H 22 Frequency 1-99 N/A - N/A - Level 0-99
Co Compressor H 8 Threshold 60-0 Ratio 1-19, inf Attack 1-10 Gain -19 to +20
D1 Mono Delay (1 tap) H 46 Delay coarse 0-1 Delay fine 0-99ms Feedback 0-99% Level 0-99
D2 Stereo Delay (1 tap) H 48 Delay course 0-0.7 Delay fine 0-99ms Feedback 0-99% Level 0-99
D1 Mono Delay (2 taps) H 50 Delay course 0-1 Delay fine 0-99ms Feedback 0-99% Level 0-99
D1 Mono Delay (1 tap) W 52 Delay course 0-2 Delay fine 0-99ms Feedback 0-99% Level 0-99
D2 Stereo Delay (1 tap) W 54 Delay course 0-1 Delay fine 0-99ms Feedback 0-99% Level 0-99
D2 Mono Delay (2 taps) W 56 Delay course 0-2 Delay fine 0-99ms Feedback 0-99% Level 0-99
D1 Karaoke H 58 Delay time 1-5 N/A - Repeats 1-10 Level 0-99
* W effects can only be used in single effect mode, H effects can be used in both single and dual modes.
