44 Discrete I/O Modules
Publication 1746-IN005A-US-P
Figure 8:Wiring Diagrams (1746-IM4, -IM8, -IM16)
IN 0
IN 1
IN 2
IN 3
IN 4
IN 5
IN 6
IN 7
AC COM
L1
L2
AC COM
200/240V ac
NOT
USED
NOT
USED
NOT
USED
NOT
USED
IN 0
IN 1
IN 2
IN 3
AC COM
L1
L2
200/240V ac
PLC
L1
L2
200/240V ac
IN 0
IN 2
IN 4
IN 6
IN 10
IN 12
IN 14
AC COM
0
2
4
6
IN 8
10
12
14
16
SLC
3
IN 5
IN 7
IN 9
IN 11
IN 13
IN 15
AC COM
11
13
15
17
5
7
IN 1
1
IN 3
1746IM4
200/240V ac
1746-IM8
200/240V ac
COMMONS
CONNECTED
INTERNALLY
1746-IM16
200/240V ac
COMMONS
CONNECTED
INTERNALLY

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Allen-Bradley 1746-IA16 and is the answer not in the manual?

Allen-Bradley 1746-IA16 Specifications

General IconGeneral
SeriesSLC 500
Part Number1746-IA16
CategoryI/O Systems
ManufacturerAllen-Bradley
Number of Inputs16
Input Voltage120V AC
Input Voltage CategoryAC
Operating Temperature0...60 °C (32...140 °F)
Storage Temperature-40...85 °C (-40...185 °F)
Product TypeDigital Input Module
Backplane Current Draw125 mA at 5V DC
Power Dissipation2.5 W
Isolation Voltage1500 V
Isolation Voltage Continuous1500 V
Relative Humidity5-95% non-condensing
CompatibilitySLC 500
