Table 10:Specifications for Input Module 1746-IN16
Specification 1746-IN16
(1)
(1)Removable Terminal Block.
Voltage Category 24V ac/dc Signal Input
Number of Inputs 16
Points per Common 16
Operating Voltage
dc 10 to 30V dc (sinking)
ac 10 to 30V ac
Backplane Current
Consumption
5V dc 0.085A
24V dc 0.0A
Signal Delay (max.)
dc
on = 15 ms
off = 15 ms
ac
on = 25 ms
off = 25 ms
Off State Voltage (max.)
dc 3.0V dc
ac 3.0V ac
Off State Current (max.)
dc 1 mA
ac 1 mA
Nominal Input Current
dc 8 mA at 24V dc
ac 8 mA at 24V ac
Inrush Current (max.) 0.02A (ac only)
