Compact I/O Expansion Power Supplies
Mount the Panel
Mount the power supply to a panel by using four screws per module. Use M4 or #8 panhead
screws. Mounting screws are required on each power supply panel mounting tab.
Panel Mounting Using the Dimensional Template
ATTENTION: This product is intended to be mounted to a well-grounded mounting surface such
as a metal panel. Additional grounding connections from the power supply's mounting tabs or DIN
rail (if used) are not required unless the mounting surface cannot be grounded. Refer to Industrial
Automation Wiring and Grounding Guidelines, Allen-Bradley publication 1770-4.1
, for additional
information.
Compact I/O
Compact I/O
End Cap End Cap
Power Supply
For more than 2 modules: (number of modules -1) X 35 mm (1.38 in.)
132
(5.197)
40
(1.58)
70
(2.76)
28.5
(1.12)
35
(1.58)
35
(1.58)
122.6 ±0.2
(4.826 ±0.008)
All dimensions are in mm (in.). Hole spacing tolerance: ±0.4 mm (0.016 in.)
