30 Rockwell Automation Publication 1769-IN028C-EN-P - August 2016
Compact I/O Expansion Power Supplies
1769-PA4 Real Power Dissipation
1769-PB4 Real Power Dissipation
Bus +5V, +24V, and User +24V Load
(Watts)
Real Power Dissipated
(Watts)
60
40
200
20
15
10
5
0
60 °C
55 °C
Bus +5V, +24V, and User +24V Load
(Watts)
Real Power Dissipated
(Watts)
60
4020
0
20
15
10
5
0
60 °C
55 °C
