Allen-Bradley 1769-PB2 User Manual

Rockwell Automation Publication 1769-IN028C-EN-P - August 2016 33
Compact I/O Expansion Power Supplies
Surge transient immunity
IEC61000-4-5
±2 kV line-line (DM) and
±4 kV line-earth (CM) on
AC power ports
±500V line-line (DM) and
±500V line-earth (CM) on
24V DC PWR OUT ports
±500 V line-line (DM) and
±1 kV line-earth (CM) on
DC power ports
±2 kV line-line (DM) and
±4 kV line-earth (CM) on
AC power ports
±500 V line-line (DM) and
±1 kV line-earth (CM) on
DC power ports
Conducted RF Immunity
IEC61000-4-6
10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80 MHz
Voltage variation
IEC 61000-4-11
30% dips for 1 period at 0°
and 180° on AC supply
ports
60% dips for 5 and 50
periods on AC supply ports
±10% fluctuations for 15
min on AC supply ports
>95% interruptions for
250 periods on AC supply
ports
N/A 30% dips for 1 period at 0°
and 180° on AC supply
ports
60% dips for 5 and 50
periods on AC supply ports
±10% fluctuations for 15
min on AC supply ports
>95% interruptions for
250 periods on AC supply
ports
N/A
Voltage variation
IEC 61000-4-29
N/A 10 ms interruption on DC
supply ports
N/A 10 ms interruption on DC
supply ports
Certifications
Certifications
(1)
(1) See the Production Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
1769-PA2, 1769-PA4 1769-PB2, 1769-PB4
c-UL-us UL Listed for Class 1, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E10314
CE European Union 2014/30/EU EMC Directive, compliant
with:
• EN 61000-6-2; Industrial Immunity
• EN 61000-6-4; Industrial Emissions
European Union 2014/35/EU LVD, compliant with:
• EN 61131-2; Programmable Controllers (Clause 11)
European Union 2014/30/EU EMC Directive, compliant
with:
• EN 61000-6-2; Industrial Immunity
• EN 61000-6-4; Industrial Emissions
RCM Australian Radio Communications Act, compliant with:
• AS/NZS CISPR 11; Industrial Emissions
Ex N/A European Union 2014/34/EU ATEX Directive, compliant
with:
• EN 60079-15; Potentially Explosive Atmospheres,
Protection “n” (II 3 G Ex nA IIC T4 X)
• EN 60079-0; General Requirements (Zone 2)
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Environmental Specifications (Continued)
Attribute 1769-PA2 1769-PB2 1769-PA4 1769-PB4
