Appendix B Accessories and Dimensions
Table 27 - Communication Option Kits and Accessories
Item Description Catalog Number
BACnet® MS/TP RS-485
Communication Adapter
Embedded communication options for use with the
PowerFlex family of drives.
Requires a Communication Adapter Cover when used with
Frame C PowerFlex 400 drives (Ordered Separately).
22-COMM-B
ControlNet™
Communication Adapter
22-COMM-C
DeviceNet™
Communication Adapter
22-COMM-D
EtherNet/IP™
Communication Adapter
22-COMM-E
LonWorks™
Communication Adapter
22-COMM-L
PROFIBUS™ DP
Communication Adapter
22-COMM-P
External DSI™
Communications Kit
External mounting kit for 22-COMM communication adapter
options.
22-XCOMMDC-BASE
External Comms Power
Supply
Optional 100-240V AC Power Supply for External DSI
Communications Kit.
20-XCOMMAC-PS1
Compact I/O Module 3 Channel. 1769-SM2
Communication Adapter
Cover
Cover that houses the communication adapter.
Frame C Drive
22C-CCC
DSI Cable 2.0 meter RJ45 to RJ45 cable, male to male connectors. 22-RJ45CBL-C20
Serial Cable 2.0 meter serial cable with a locking low profile connector to
connect to the serial converter and a 9-pin sub-miniature D
female connector to connect to a computer.
1203-SFC
Serial Null Cable Converter For use when connecting the serial converter to
DriveExplorer on a handheld PC.
1203-SNM
Universal Serial Bus™
(USB) Converter
Includes 2m USB, 20-HIM-H10 & 22-HIM-H10 cables. 1203-USB
Splitter Cable RJ45 one to two port splitter cable AK-U0-RJ45-SC1
Terminating Resistors RJ45 120 Ohm resistors (2 pieces) AK-U0-RJ45-TR1
Terminal Block RJ45 Two position terminal block (5 pieces) AK-U0-RJ45-TB2P
Connected Components
Workbench Software
(Download or DVD-ROM)
Windows based software packages for programming and
configuring Allen-Bradley drives and other Rockwell
Automation products.
Compatibility:
Windows XP, 7 Professional (Service Pack 1, 32-bit) and
Vista (Service Pack 1 and 2, 32-bit).
http://
www.rockwellautom
ation.com/global/
support/connected-
components/
workbench.page?
DriveExecutive software
(CD-ROM) Version 1.01 or
later
Windows based software package that provides an intuitive
means for monitoring or configuring Allen-Bradley drives
and communication adapters online and offline.
Compatibility:
Windows 98, ME, NT 4.0 (Service Pack 3 or later), 2000,
XP, 7 Professional (Service Pack 1, 32-bit), and Vista
(Service Pack 1 and 2, 32-bit).
9303-4DTE01ENE
Serial Flash Firmware Kit Use a PC to update drive firmware. AK-U9-FLSH1
