Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 135
Accessories and Dimensions Appendix B
Table 28 - Human Interface Module (HIM) Option Kits and Accessories
Item Description Catalog Number
LCD Display,
Remote Panel Mount
LCD Display
Digital Speed Control
CopyCat Capable
IP66 indoor use only
Includes 2.0 meter cable
22-HIM-C2S
LCD Display,
Remote Handheld
LCD Display
Digital Speed Control
Full Numeric Keypad
CopyCat Capable
IP30
Includes 1.0 meter cable
Panel Mount with optional Bezel Kit
22-HIM-A3
Bezel Kit Panel mount for LCD Display, Remote Handheld unit, IP30 22-HIM-B1
DSI HIM Cable
(DSI HIM to RJ45 cable)
1.0 Meter (3.3 Feet)
2.9 Meter (9.51 Feet)
22-HIM-H10
22-HIM-H30
Table 29 - Frame C IP30 Kit
Item Description Drive
Frame
Catalog
Number
IP30/NEMA 1/UL Type 1
Kit
Field installed kit. Converts drive to IP30/ NEMA 1/UL Type 1
enclosure. Includes conduit box with mounting screws and
plastic top panel.
C 22-JBAC
IP30/NEMA 1/UL Type 1
Kit for Communication
Option
Field installed kit. Converts drive to IP30/ NEMA 1/UL Type 1
enclosure. Includes communication option conduit box with
mounting screws and plastic top panel.
C 22-JBCC
Table 30 - Field Installed Option
Item Description Catalog Number
Auxiliary Relay Board Field installed kit. Expands drive output capabilities. AK-U9-RLB1
