Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 131
Accessories and Dimensions Appendix B
Table 22 - Bulletin 1321-3R Series Line Reactors – 200...240V, 60 Hz, 3-Phase
kW HP Fundamental
Amps
Maximum
Continuous
Amps
Inductance
mh
Watts Loss Catalog Number
IP00
(Open Style)
IP11
(NEMA Type 1)
3% Impedance
2.2 3.0 12 18 1.25 26 1321-3R12-A 1321-3RA12-A
3.7 5.0 18 27 0.8 36 1321-3R18-A 1321-3RA18-A
5.5 7.5 25 37.5 0.5 48 1321-3R25-A 1321-3RA25-A
7.5 10 35 52.5 0.4 49 1321-3R35-A 1321-3RA35-A
11 15 45 67.5 0.3 54 1321-3R45-A 1321-3RA45-A
15 20 55 82.5 0.25 64 1321-3R55-A 1321-3RA55-A
18.5 25 80 120 0.2 82 1321-3R80-A 1321-3RA80-A
22 30 80 120 0.2 82 1321-3R80-A 1321-3RA80-A
30 40 100 150 0.15 94 1321-3R100-A 1321-3RA100-A
37 50 130 195 0.1 108 1321-3R130-A 1321-3RA130-A
5% Impedance
2.2 3.0 12 18 2.5 31 1321-3R12-B 1321-3RA12-B
3.7 5.0 18 27 1.5 43 1321-3R18-B 1321-3RA18-B
5.5 7.5 25 37.5 1.2 52 1321-3R25-B 1321-3RA25-B
7.5 10 35 52.5 0.8 54 1321-3R35-B 1321-3RA35-B
11 15 45 67.5 0.7 62 1321-3R45-B 1321-3RA45-B
15 20 55 82.5 0.5 67 1321-3R55-B 1321-3RA55-B
18.5 25 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
22 30 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
30 40 100 150 0.3 84 1321-3R100-B 1321-3RA100-B
37 50 130 195 0.2 180 1321-3R130-B 1321-3RA130-B
Table 23 - Bulletin 1321-3R Series Line Reactors – 380...480V, 60 Hz, 3-Phase
kW HP Fundamental
Amps
Maximum
Continuous
Amps
Inductance Watts Loss Catalog Number
IP00
(Open Style)
IP11
3% Impedance
2.2 3.0 8 12 5 25.3 1321-3R8-C 1321-3RA8-C
4.0 5.0 12 18 2.5 31 1321-3R12-B 1321-3RA12-B
5.5 7.5 12 18 2.5 31 1321-3R12-B 1321-3RA12-B
7.5 10 18 27 1.5 43 1321-3R18-B 1321-3RA18-B
11 15 25 37.5 1.2 52 1321-3R25-B 1321-3RA25-B
15 20 35 52.5 0.8 54 1321-3R35-B 1321-3RA35-B
18.5 25 35 52.5 0.8 54 1321-3R35-B 1321-3RA35-B
22 30 45 67.5 0.7 62 1321-3R45-B 1321-3RA45-B
30 40 55 82.5 0.5 67 1321-3R55-B 1321-3RA55-B
37 50 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
45 60 80 120 0.4 86 1321-3R80-B 1321-3RA80-B
55 75 100 150 0.3 84 1321-3R100-B 1321-3RA100-B
75 100 130 195 0.2 180 1321-3R130-B 1321-3RA130-B
90 125 160 240 0.15 149 1321-3R160-B 1321-3RA160-B
110 150 200 300 0.11 168 1321-3R200-B 1321-3RA200-B
