Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 151
Accessories and Dimensions Appendix B
Figure 29 - NEMA Type 1 Bezel
Dimensions are in millimeters and (inches)
Catalog Number: 22-HIM-B1
93
(3.66)
25.2
(0.99)
2m
180
(7.09)
11.1
(0.44)
19.1
(0.75)
4.8
(0.19)
154
(6.06)
77
(3.03)
23.5
(0.93)
67
(2.64)
60
(2.36)
