Bulletin 700S-P
Safety Control Relays
10
Specifications
➊ Coil voltage required for proper operation (percent of rated coil voltage).
➋ Temperature inside the panel.
➌ 90% of devices are expected to meet or exceed 12.5 million operations, and 50% of devices are are expected to meet 20 million operations.
Type 700S-P
Electrical
Contact Rating Continuous
10 A @ 600V AC
5 A @ 600V DC
Ratings
Make/Break
AC NEMA A600
DC NEMA P600
Minimum Contact Switching Ratings 10V, 50 mA
DC Switching
Contacts
in Series
Volts DC
24 64 125 250 500 600
1 5 A 2.2 A 1.1 A .55 A .24 A .2 A
2 10 A 10 A 5 A 2 A .7 A .5 A
3 — — 7 A 3 A 1.5 A 1.0 A
4 — — 10 A 5 A 2.5 A 1.5 A
Contact Electrical Life—Resistive Loads
1.5 million operations at 10A break at 120V AC
14 million operations at 1A break at 120V AC
6 million operations at 1A break at 24V DC
Coil Voltage Range
➊
AC 85…110%
DC 80…110%
Battery
Charging
85…115%
Coil Consumption
50 Hz 60 Hz
AC
Inrush 132 VA 138 VA
Sealed 19.3 VA 19 VA
DC
Inrush 12.7 W
Sealed 12.7 W
Mechanical
Mechanically Linked Contacts All contacts are mechanically linked per IEC 947-5-1 annex L for 2 to 12 poles
Operating Time
Pickup
AC – 10…20 ms
DC – 30…50 ms
Dropout
AC – 10…20 ms
DC – 20…33 ms
Mechanical Life
12.5 million operations
➌
Construction
Contact Arrangement
2 to 12 Poles, Double Break Contacts
N.O. or N.C. (8 N.C. Maximum)
Contact Material/Design Silver Nickel/Bifurcated
Mounting
Panel mount or mount on 700-MP Rail
Horizontal Mounting Recommended
Environmental
Temperature
Operating
➋
–20…+65°C (–4…149°F)
Storage –40…+65°C (–40…149°F)
Wire Terminations
Wire size per UL/CSA 1X #18 AWG…2X #12 AWG
Tightening Torque 8…12 lb-in. (0.9…1.4 N•m)
