Allen-Bradley Bulletin 700S-CF User Manual

Bulletin 700S-CF
Safety Control Relays
6
Specifications, Continued
Control Circuit
➊ For 9V DC, code ZR, use operating voltage 0.65… 1.3 x U
s
.
For 24V DC, code ZJ or DJ, use operating voltage 0.7… 1.25 x U
s
.
General
➋ 8 kV for main poles, 6 kV for front aux. contacts.
➌ 40 degree max. for 700S-CF350 with DC coil.
➍ Operation in 70°C ambient is permitted with current reduction of 15%
below rated values
Cat. No.
700S-CF
Operating Voltage
AC 50/60
Hz Pickup
[x U
s
]
0.85…1.1
Dropout
[x U
s
]
0.3…0.6
DC ➊ Pickup
[x U
s
]
0.8…1.1
Dropout
[x U
s
]
0.1…0.6
Coil Consumption at nominal voltage
AC 50/60
Hz Inrush [VA/W] 70/50
Seal [VA/W] 8/2.6
DC
Inrush/Seal
warm coil
[W] 6.5
Inrush/Seal
cold coil
[W] 8.5
Operating Times
AC 50/60
Hz Pickup Time [ms] 15…30
Dropout Time [ms
]
10…60
DC Pickup Time [ms] 40…70
Dropout Time [ms
]
7…15
With integrated suppression [ms
]
14…20
With diode
suppression
[ms
]
70…95
Cat. No. 700S-CF
Rated Insulation Voltage
U
i
IEC 690V
UL; CSA 600V
Dielectric Withstand Voltage
2500V
Rated Impulse Strength
U
imp
8 kV ➋
Rated Voltage
U
e
AC 115, 230, 400, 500, 690V
DC 24, 48, 110, 220, 440V
Short-Circuit Protection IEC 947-5
Fuse-Type GG
20 A
Rated Frequency
50/60 Hz, DC
Ambient Temperature
Storage –55…+80°C (–67…176°F)
Operation at nominal current –25…+60°C (–13…140°F)➌➍
Corrosion Resistance
humid-alternating climate,
cyclic, per IEC 68-2-30 and
DIN 50 016, 56 cycles
Altitude
2000 m above mean sea level,
per IEC 947-4
Type of Protection
IP2X in connected state
Finger Protection
safe from touch by fingers and
back of hand per VDE 0106,
Part 100
