Allen-Bradley Micro850 series User Manual

14 Micro850 48 Point Programmable Controllers
Publication 2080-IN008C-EN-P - August 2017
Specifications
General Specifications
Attribute 2080-LC50
-48AWB -48QWB -48QVB -48QBB
Number of I/O 48 (28 inputs, 20 outputs)
Dimensions
HxWxD
90 x 238 x 80 mm
(3.54 x 9.37 x 3.15 in.)
Shipping
weight, approx.
0.725 kg (1.60 lb)
Wire size
Wiring
category
(1)
2 – on signal ports
2 – on power ports
2 – on communication ports
Wire type Use Copper Conductors only
Terminal screw
torque
0.4…0.5 Nm (3.5…4.4 lb-in.)
using a 0.6 x 3.5 mm flat-blade screwdriver.
Input circuit
type
120V AC 12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit
type
Relay 24V DC sink
(standard and
high-speed)
24V DC source
(standard and
high-speed)
Power
consumption
33 W
Power supply
voltage range
21.4…26.4V DC Class 2, or
Limited Voltage Limited Current Source (LVLC)
I/O rating Input 120V AC,
16 mA
Output 2 A,
240V AC,
2A, 24V DC
Input 24V, 8.8 mA
Output 2 A,
240V AC, 2 A, 24V
DC
Input 24V, 8.8 mA
Output 24V DC, 1 A per point
(surrounding air temperature 30 °C)
24V DC, 0.3 A per point (surrounding
air temperature 65 °C)
Insulation
stripping length
7 mm (0.28 in.)
Enclosure type
rating
Meets IP20
Min Max
Solid and
Stranded
0.2 mm
2
(24 AWG)
2.5 mm
2
(14 AWG)
rated @ 90 °C
(194 °F ) insulation max
