Allen-Bradley Micro850

Micro850 24-Point Programmable Controllers 17
Publication 2080-IN007A-EN-P - September 2012
On-state voltage range 16.8…26.4V DC @ 65°C (149°F)
16.8…30.0V DC @ 30°C (86°F)
10…26.4V DC @ 65°C (149°F)
10…30.0V DC @ 30°C (86°F)
Off-state voltage 5V DC, max
Off-state current 1.5 mA, max
On-state current 5.0 mA @ 16.8V DC, min
7.6 mA @ 24V DC, nom
12.0 mA @ 30V DC, max
1.8 mA @ 10V DC, min
6.15 mA @ 24V DC, nom
12.0 mA @ 30V DC, max
Nominal impedance 3 kΩ 3.74 kΩ
IEC input compatibility Type 3
IMPORTANT
For 24V AC specifications, refer to the Micro830 and Micro850 User Manual,
publication 2080-UM002.
AC Input Specifications – 2080-LC50-24AWB
Attribute Value
Number of Inputs 14
On-state voltage 79 V AC, min
132V AC, max
On-state current 5 mA, min
16 mA, max
Input frequency 50/60 Hz, nom
47 Hz, min
63 Hz, max
Off-state voltage 20V AC @ 120V AC, max
Off-state current 2.5 mA @ 120V AC, max
Inrush current 250 mA @ 120V AC, max
Inrush delay time
constant max
22 ms
IEC input compatibility Type 3
DC Input Specifications – 2080-LC50-24QBB, 2080-LC50-24QVB,
2080-LC50-24QWB
Attribute High-Speed DC Input
(Inputs 0…7)
Standard DC Input
(Inputs 8 and higher)
