Allen-Bradley Micro850 - General Specifications; DC Input Specifications (General)

16 Micro850 24-Point Programmable Controllers
Publication 2080-IN007A-EN-P - September 2012
Isolation
voltage
250V (continuous),
Reinforced Insulation
Type, Output to Aux
and Network, Inputs
to Outputs.
Type tested for 60 s
@ 3250V DC Output
to Aux and Network,
Inputs to Outputs
150V (continuous),
Reinforced Insulation
Type, Input to Aux
and Network.
Type tested for 60 s
@ 1950V DC Input to
Aux and Network
250V (continuous),
Reinforced Insulation
Type, Output to Aux
and Network, Inputs
to Outputs.
Type tested for 60 s @
3250V DC Output to
Aux and Network,
Inputs to Outputs.
50V (continuous),
Reinforced Insulation
Type, Input to Aux and
Network
Type tested for 60 s @
720V DC, Inputs to
Aux and Network
50V (continuous), Reinforced Insulation
Type, I/O to Aux and Network, Inputs to
Outputs.
Type tested for 60 s @ 720 V DC, I/O to Aux
and Network, Inputs to Outputs.
Pilot duty
rating
C300, R150 –
Insulation
stripping
length
7 mm (0.28 in.)
Enclosure
type rating
Meets IP20
North
American
temp code
T4
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1
.
DC Input Specifications – 2080-LC50-24QBB, 2080-LC50-24QVB,
2080-LC50-24QWB
Attribute High-Speed DC Input
(Inputs 0…7)
Standard DC Input
(Inputs 8 and higher)
Number of Inputs 8 6
Voltage category 24V sink/source
Input group to
backplane isolation
Verified by one of the following dielectric tests: 720V DC for 2 s
50V DC working voltage (IEC Class 2 reinforced insulation)
General Specifications – 2080-LC50-24AWB, 2080-LC50-24QBB,
2080-LC50-24QVB, 2080-LC50-24QWB
Attribute 2080-LC50-24AWB 2080-LC50-24QWB 2080-LC50-24QVB 2080-LC50-24QBB
