Drawing a Circuit with Pico 2-25
Motor Start/Stop Circuit
I1 I2 Contact
Q1
Coil
Q1
000 0
101 1
001 1
010 0
110 0
I1--I2-----{Q1
Q1
I1--------SQ1
I2--------RQ1
Alternatively:
