Allen-Bradley PicoTM Controller 1760 User Manual

Publication 1760-GR001C-EN-P - April 2005
A-2 Specifications
1760-L12BWB 8 (24V dc) 4 (relay) 24V dc Yes Yes 2 (0 to 10V dc)
1760-L12BWB-NC
(1)
No Yes
1760-L12BWB-ND
(2)
Yes No
1760-L12BBB 4 (MOSFET) Yes Yes 2 (0 to 10V dc)
1760-L12BBB-ND Yes No
1760-L12NWA 8 (24V ac) 4 (relay) 24V ac Yes Yes
1760-L12NWA-ND Yes No
1760-L12DWD 8 (12V dc) 12V dc Yes Yes
1760-L12DWD-ND Yes No
1760-L18BWB-EX
(3)
12 (24V dc) 6 (relay) 24V dc Yes Yes
1760-L18BWB-EXND
(2)(3)
6 (relay) Yes No 2 (0 to 10V dc)
1760-L20BBB-EX
(3)
8 (MOSFET) Yes Yes 4 (0 to 10V dc)
1760-L20BBB-EXND
(2)(3)
8 (MOSFET) Yes No
1760-L18DWD-EX
(3)
12 (12V dc) 6 (relay) 12V dc Yes Yes
1760-L18DWD-EXND
(2)(3)
6 (relay) 12V dc Yes No
1760-L18NWA-EX
(3)
12 (24V ac) 6 (relay) 24V ac Yes Yes 4 (0 to 10V dc)
1760-L18NWA-EXND
(2)(3)
12 (24V ac) 6 (relay) Yes No
(1) NC = no real time clock
(2) ND = no display
(3) EX = suitable for use with expansion modules
Catalog Number Inputs Outputs Line Power Real Time
Clock
Display and
Keypad
Analog

Allen-Bradley PicoTM Controller 1760 Specifications

General

Brand	Allen-Bradley
Model	PicoTM Controller 1760
Category	Network Hardware
Language	English
