Allen-Bradley PowerFlex 20-750-DCBB2-F6 - Page 5

Rockwell Automation Publication 750-IN009D-MU-P - June 2017 5
PowerFlex 750-Series DC Bus Bars – Frame 6 and 7
5.20 N•m (46 lb•in)
8
PE-B
T30
Frame 7 - 200…240V & 400…480V Frame 7 - 600/690V
Terminate the PE-B jumper wire in the same
position as noted in Step 5 on page 3
.
T30
5.2 N•m (46 lb•in)
T25
2.6 N•m (23 lb•in)
T30
5.2 N•m (46 lb•in)
T25
2.6 N•m (23 lb•in)
9
A A
B
Frame 7 - 200…240V & 400…480V
Frame 7 - 600/690V
