Allen-Bradley PowerFlex 20-750-S1 User Manual

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 105
Lift and Mount the Drive Chapter 3
Figure 66 - NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9
Enclosure Code L, P, W - 800 mm Deep Drive with Wiring Bay.
M12 (1/2 in.) Property Class 8.8 anchoring hardware recommended to
fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts may be pre-located and embedded in the
foundation prior to instillation.
➊➊
➋
2453
(96.6)
1800
(70.9)
2300
(90.6)
440
(17.3)
78
(3.1)
➊➊
➋
➎
➍
268
(10.5)
1464
(57.6)
➌
➊➊
440
(17.3)
800
(31.5)
240
(9.4)
440
(17.3)
➊
266
(10.5)
266
(10.5)
127
(5.0)
➋➋
127
(5.0)
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
➌ Optional exhaust hood.
➍ Optional HIM.
➎ Recommended six-hole anchoring.
BOTTOM
TOP
