Allen-Bradley PowerFlex 20-750-S1 User Manual

104 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 65 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
Enclosure Code L, P, W - 800 mm Deep Drive with Cabinet Options Bay.
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
440
(17.3)
440
(17.3)
200
(7.9)
➊
➊
➋
➊
➋
1269
(50.0)
1500
(59.1)
1731
(68.1)
292
(11.5)
127
(5.0)
440
(17.3)
76
(3.0)
76
(3.0)
