68 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 30 - Flange Mount, Frame 7
Dimensions are in millimeters and (inches).
875.0
(34.45)
430.0
(16.93)
208.4
(8.20)
138.0
(5.43)
509.6
(20.06)
28.0
(1.10)
431.2
(16.98)
352.8
(13.89)
274.4
(10.80)
196.0
(7.72)
117.6
(4.63)
588.0
(23.15)
666.4
(26.24)
744.8
(29.32)
784.0
(30.87)
812.0
(31.97)
39.2
(1.54)
768.0
(30.24)
50.38 (1.98)
151.13 (5.95)
251.88 (9.92)
352.63 (13.88)
403.00 (15.87)
32x: Ø7.0
(Ø0.28)
387.0
(15.24)
8.0
(0.31)
8.0
(0.31)
IMPORTANT
Must use Flange Adapter kit (20-750-FLNG4-F7) to meet enclosure rating.
