Allen-Bradley PowerFlex 20-750-S1 User Manual

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 73
Lift and Mount the Drive Chapter 3
Figure 35 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9 (Enclosure Code B)
M12 (1/2 in.) Property Class 8.8 anchoring hardware recommended to
fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts may be pre-located and embedded in the
foundation prior to instillation.
2453
(96.6)
1200
(47.2)
2300
(90.6)
440
(17.3)
600
(23.6)
240
(9.4)
ø18.0
(0.71)
68
(2.7)
542
(21.3)
1183
(46.6)
500
(19.7)
43
(1.7)
69
(2.7)
127
(5.0)
76
(3.0)
➊
➋
76
(3.0)
➊
➋
500
(19.7)
141
(5.6)
76
(3.0)
127
(5.0)
➊
➋
440
(17.3)
127
(5.0)
➊
➋
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
➎
➍
1464
(57.6)
➌
BOTTOM
BOTTOM
TOP
No. Description No. Description
➊ Power wiring conduit plates. ➍ Optional HIM.
➋ Control wiring conduit plates. ➎ Recommended four-hole anchoring.
➌ Optional exhaust hood.
