Allen-Bradley PowerFlex 20-750-S1 User Manual

78 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 40 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 10
(Enclosure Codes L, P, W)
M12 (1/2 in.) Property Class 8.8 anchoring hardware recommended to
fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts may be pre-located and embedded in the
foundation prior to instillation.
1800
(70.9)
800
(31.5)
240
(9.4)
➏
➎
440
(17.3)
440
(17.3)
➊➊
➍
➍ ➍
440
(17.3)
270
(10.6)
➊
2453
(96.6)
2300
(90.6)
1862
(73.3)
1464
(57.6)
➌➌
127
(5.0)
76
(3.0)
➋
127
(5.0)
➋
127
(5.0)
➋
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
➌ Optional exhaust hood.
➍ Disconnect switches (SW2). Common DC Input
drives.
➎ Optional HIM.
➏ Recommended seven-hole anchoring.
BOTTOM
TOP
