Allen-Bradley PowerFlex 20-750-S1 User Manual

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 77
Lift and Mount the Drive Chapter 3
Figure 39 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 10 Bottom Access
(Enclosure Code B)
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
ø18.0
(0.71)
542
(21.3)
1183
(46.6)
500
(19.7)
43
(1.7)
69
(2.7)
76
(3.0)
➊
➋
500
(19.7)
76
(3.0)
➊
➋
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
1269
(50.0)
1500
(59.1)
1731
(68.1)
500
(19.7)
141
(5.6)
76
(3.0)
127
(5.0)
➊
➋
