16. Connect the Track Beam (E) to the Crossbeam
(B1/B2/B3/B3) with Bolt (CC) and
Plastic Washer
(GG). Tighten together with the Wrench (NN).
Place
Cap (II) on the Bolt (CC).
Hardware Used
16
M6 × 95 mm Bolt
X6
X6
X6
Cap
Plastic Washer
CC
GG
II
X1
Wrench
NN
