ASSEMBLY INSTRUCTIONS
1. Insert the Post (A) into the Base Cover (M) and
connect it to the Base (L) with Bolt (AA) and Flat
Washer (FF). Tighten together with the Wrench
(NN). Connect the other Posts in the same way.
When all the Posts are ready, place them in
position.
