Allfett ALL-1 PS - SYSTEM COMPONENTS AND FUNCTIONALITY; PRODUCT COMPONENTS ILLUSTRATION

PAGE 5
www.allfett.net
PRODUCT COMPONENTS
Technical drawings below represents the ALL-1 PS pumps standard model and ALL-1 Pump with
integrated control model. Optional specifications described seperately.
Pump
element
(Optional)
Exhaust
Reservoir cover
Reservoir
6 liters
Follower
piston
Grease
nipple
Filling
filter
(Optional)
Assembly
holes
Electrical socket
Motor cover screws
Pump element positions
Integrated control card
(Optional)
Motor cover
Pump
body
Agitator
Exhaust
inlet
Standard Pump
Pump with integrated controller
