TABLE OF CONTENTS
Specications and Features.......................pg 3
How to Download the App .......................pg 4
Basic Functions.........................................pg 5
How to Create a Secured Network.........pgs 6-9
How to Name a Fixture ............................pg 10
How to Create a Group ......................pgs 12-14
Online video library available at:
www.allianceoutdoorlighting.com/bt-support
What’s in the Box?
Fixture Features:
Body: Solid brass with an aged brass nish
Knuckle: Solid brass with dial for easy adjustments
Shroud: Brass with clear glass convex lens and double gasket
Wire: Industry First, double wire lead pre-connected to the
xture, 16 awg (UL listed), brown
-25 foot wire lead, pre-stripped for easy
wire connection
-18 inch wire lead, LED connection ready
Stake: Plastic ground stake, attached to the xture
Warranty: Ten Year Warranty on Integrated Fixture
Certication: Complies with the requirements of UL-1838 and
CAN/CSA-C22.2 No. 250.7. Identied with the ETL and cETL
Listed Mark.
Integrated LED Features:
Wattage: 2w - 6w
Operating Voltage Range: 10v - 14v
Lumen Output: 10lm to 350lm
Beam Spread: 40°
CRI: 80
CCT Options: 2700K, 3000K, 4000K
RGB Options: Unlimited Color Wheel Options with quick preset
options for Red, Green, Blue, Amber and Purple
Dimming: Dimming option available for every color choice
Scenes: Preset scenes of Red+Green, Purple+Orange, and
Red+White+Blue
7.25 in. (18.42 cm)
2.5 in. (6.35 cm)
1.75 in. (4.45cm)
3
· Bluetooth Mesh Technology
· Phone App Driven
· Tunable White
· Adjustable RGB Color
· Preset Scenes
· Dimming Capable
· Grouping Capable
· No Special Equipment Needed
· Ready To Install
· List Price: $175.00
