Allied Telesis AT-MWS2533AP User Manual

Chapter 1: Product Description
14
Overview
The MWS series access point is designed to accommodate
traffic-intensive applications such as multimedia streaming. The access
point is equipped with one or two PoE+ capable LAN ports. With the power
supply unit with the DC jack, the PoE+ LAN port provides a redundant
power supply system to help uninterrupted operations. This device can be
mounted on a ceiling or wall.
The MWS series access point can be installed on a ceiling, wall, or
tabletop. In addition, the AT-MWS600AT and AT-MWS1750AP models
can be installed on a ceiling T-rail.
AT-MWS600AP
and
AT-MWS1750AP
Models
The AT-MWS600AP and AT-MWS1750AP models are dual band access
points with one PoE+ LAN port, which can drain power from the connected
PoE+ switch. Both models share the physical design and size. See
Figure 1.
Figure 1. Top View of the AT-MWS1750AP Model
The bottom view of the AT-MWS600AP and AT-MWS1750AP models is
illustrated in Figure 2.
Figure 2. Bottom View of the AT-MWS600AP and 1750AP Models
LAN Port
DC Jack

Allied Telesis AT-MWS2533AP Specifications

General

Model	AT-MWS2533AP
Type	Wireless Access Point
Frequency Bands	2.4 GHz and 5 GHz
Ethernet Ports	1 x 10/100/1000 Mbps
Mounting Options	Wall or ceiling
Antenna Type	Internal
Humidity	10% to 90% non-condensing
Wireless Standards	IEEE 802.11a/b/g/n
Power over Ethernet (PoE)	802.3af PoE
Operating Temperature	0°C to 40°C (32°F to 104°F)
Antenna Gain	2.4GHz: 3dBi, 5GHz: 4dBi
Storage Temperature	-20 to 70 °C
MIMO Technology	2x2 MIMO
